ITEM
Overall gain
Equipment:
* AF oscillator
* VTVM
* ATT
* Oscilloscope
* Test tape
(reference biank tape)
C-RA for Normal
Level meter
Equipment :
* VTVM
* Oscilloscope
* AF oscillator
* ATT
MEASUREMENT & ADJUSTMENT
1. Test equipment connection is shown in fig. 15.
Record mode
LINE IN
AF oscillator
Test tape
R/P head
Playback mode VTVM Oscilloscope
Test tape
Fig. 15
. Place UNIT into record mode, and equalizer selector to 1204S, bias
selector to LOW (for normal tape).
Supply 1 kHz signal (—24dB) from AF oscillator, through ATT, to
LINE IN.
. Adjust ATT until monitor level at LINE OUT becomes 0.42 V (—7 dB).
. Using test tape (C-RA), make recording
. Playback recorded tape, and make sure the value at LINE OUT on
VTVM becomes 0.42 V.
If measured value is not 0.42 V, adjust VR5 (L-CH), VR6 (R-CH) (See
fig. 20 on page 12).
. Repeat from step (2).
1. Supply 1kHz signal (~24dB) from AF oscillator, through ATT, to
LINE IN jack.
2. Place UNIT into record mode.
3. Adjust ATT until monitor level at LINE OUT becomes 0.42 V,
4. Short or open the connection point {D) and (E) so that VU meter indi-
cates O+ 1 VU (See fig. 19 on page 12).
Overall distortion
Equipment:
* Distortion meter
* AF oscillator
* ATT
* Oscilloscope
* Test tape
(reference blank tape)
C-RA for Normal
C-RF for CrOs
REMARKS
+ Record/playback mode
* Record level contro
«MAX
* Input selector---LINE IN
* Standard input level:
MIC +++ +++ —72+3dB
LINE IN —24+3dB
DIN +++ —362+3dB
* Record mode
1. Test equipment connection is shown in fig. 16.
Ww
LINE IN
R/P head
“ aTT 6002 Record
mode Test tape
LINE OUT
AF oscillator
R/P head
Playback mode
Distortion
meter
Fig. 16
Test tape
Supply 1kHz signal to LINE IN and adjust ATT so that output level
at LINE OUT indicates 0.42 V (— 7 dB).
Make recording.
Playback and measure distortion factor of output signal.
* Record level control
--- MAX
* input selector---LINE IN
