Equalizer/
Headphones
C
Recording through the
built-in microphone (MIC)
B
Recording from an externally connected CD
player etc.
A
10
RQT7611
• Four types of sound effects can be selected.
The selected sound effect button lights.
CLEAR: Lightens pop and other music
SOFT: Allows background music enjoyment
HEAVY: Adds punch to rock
VOCAL: Enhances vocals
FLAT: No sound effects used
• You can adjust XBS effect to boost the bass.
When you initially apply the power source
• The preset equalizer will automatically reset to “HEAVY” when the
unit is turned on.
When the unit is in condition and when the power
source is connected
• The last preset equalizer setting will be retained when you turn on
the “CD/LINE IN”, “RADIO” or “TAPE” function.
Note
Face towards the sound source.
• When recording through the built-in microphone, no sound can be
heard from the speakers.
Note
Other functions
Equalizer
Recording through the built-in microphone
(MIC)
Headphones
To connect headphones,
Plug type: 3.5 mm stereo
Plug in firmly. Avoid listening for prolonged periods of time to prevent
hearing damage.
B
C
C
Connect the CD player (External equipment).
Start recording, then start the CD playback.
• Turn off all equipment before making any connection.
• Refer to the operating instructions of the other equipment for
details. (Cables and equipment not included.)
• If the signal level from the connected equipment is low, sound is
recorded at a low volume. When the sound is low when playing a
recorded tape, set the [CD/LINE IN] switch ( ) on the rear panel
to “HIGH” and try recording again.
Recording from an externally connected CD
player etc.
A
SELECTOR
CD/
LINE IN
RADIO
TAPE/
34
21
CD/LINE IN
NORMAL HIGH
CD/LINE IN
a
SELECTOR
HIGH/
STEREO/II
MIC/
MONO/I
NORMAL/
STEREO/II
EDIT/FM MODE/BP
CD/
LINE IN
RADIO
TAPE/
12
34
MIC
XBS
HEAVY
VOCAL
SOFT
FLAT
CLEAR
PHONES
MIN MAX
CD player,etc.
White (L)
Red (R)
Stereo connection
cable
RX-CT65RQT761104.2.610:24ページ10
