Pin
No.
Mark I/O Function
16 D3+ O Motor driver (3) forward-
action output
17 D4- O Motor driver (4) reverse-
action output
18 D4+ O Motor driver (4) forward-
action output
19 NC - N.C.
20 PGND2 - Ground connectin (2) for
driver
21 PVCC2 I Power supply (2) for driver
22 NC - N.C.
23 VCC I Power supply terminal
24 VREF I Reference voltage input
25 IN4 I Motor driver (4) input
26 IN3 I Motor driver (3) input
27 RSTIN I Reset terminal
28 NC - N.C.
- IC801 (M38224M6H104) Microprocessor
Pin
No.
Mark I/O Function
1 VLCD2 - LCD power source
2 VLCD1 - LCD power source
3 KEY_1 A-D Key 1 input
4
REM_CTL
O Control on/off of remote
sensor
5 REG_2 A-D Region setting 2
6 REG_1 A-D Region setting 1
7 R_CTL O Region control
8 P.DET A-D Power detect input
9 REG_3 I Region setting 3
10 N.C - N.C.
11 CD_SEL I CD mode selector input
12 TU_SEL I Tuner mode selector input
13 TP_SEL I Tape mode selector input
14 REC H I Record H input
15 B.P.1 - N.C.
16 N.C - N.C.
17 SEL_IN I Function mode selection
