Panasonic RX-D10 - Page 43

Pin
No.
Mark I/O Function
18 FREF_IN I Micro-P beatproof
reference freq input
19 N.C - N.C.
20 SQCK O CD subcode data clock
21 PCNT O Power control output
22 SUBQ I CD subcode block clock
input
23
REMOTE_IN
I Remote controller input
24 BLKCK I CD subcode block clock
input
25 N.C - N.C.
26 N.C - N.C.
27 RESET - System reset input
28 XOSC IN O XOSC INPUT
29 XOSC
OUT
O XOSC OUTPUT
30 OSC IN - 4.19MHz ceramic OSC input
31 OSC
OUT
- 4.19MHz ceramic OSC
output
32 VSS - GND
33 MBP1 O Microcomputer beatproof
control 1
34 MBP2 O Microcomputer beatproof
control 2
35 MUTE_A O Audio mute
36 PLL DO I PLL if count input
37
CLOSE_SW
I CD close detect SW
38 STAT I CD status input
29 CD
RESET
O CD RST output
30
REST_SW
I CD limit SW input for the
most inner point
41 MCLK O CD signal processor
control clock output
42 MDATA O CD signal processor
control load output
43 MLD O CD signal processor
control load output
44 N.C - N.C.
45 N.C - N.C.
46 N.C - N.C.
47 T_MUTE O Tuner output mute
43
