Panasonic S-07MK2U6 - NOTE Refer to the Operating Instructions Attached to the Optional Timer Remote Controller; High-Spec Wired Remote Controller (Optional Parts); Controller; Names of Parts

5
NAMES OF PARTS
INDOOR UNIT
Timer Remote Controller (Optional parts)
High-spec Wired Remote Controller (Optional parts)
Wireless Remote Controller (Optional parts)
Refer to the Operating Instructions attached
to the optional Timer Remote Controller.
Refer to the Operating Instructions attached
to the optional High-spec Wired Remote
Controller.
Refer to the Operating Instructions attached
to the optional Wireless Remote Controller.
O
P
E
N
C
L
O
S
E
C
L
O
S
E
O
P
E
N
Intake grille
Control Panel
Airflow direction
louver
Air is discharged
evenly
Receiver
Emergency button
Vertical airflow
direction louver
Horizontal airflow
direction louver
Front panel
Air filters
Receiver
Emergency button
• Do not adjust
by hand.
• Manually
adjustable.
Y2 type (4-WAY CASSETTE 60×60)
K2 type (WALL MOUNTED)
NOTE
(CZ-RTC2)
NOTE
(CZ-RTC3)
NOTE
(Wireless type:
available for all
indoor units)
F569695_VRF_EN.fm Page 5 Thursday, August 14, 2014 3:43 PM
