4 - 7
2WAY SYSTEM
Outdoor Unit Maintenance Remote Controller
4
3. Ordinary Display Controls and Functions
Â
XX-YY R.C.
Displays the outdoor unit sub-bus address which is
currently selected.
XX = Outdoor system address on main bus line (1 – 30)
YY = Outdoor unit sub-bus address (1 – 8)
“1” appears when there is only 1 outdoor unit.
LED
1
2
3
Locations where
À
,
Á
, and
Â
are displayed
as shown in Fig. 3.
01: <No. of connected indoor units>
4 units connected
<Sample displays>
02: <Unit Nos. 1, 2, 3, and 4 are
connected>
Fig. 3
Fig. 4 Fig. 5
SM830204-05_2WAY SYS.indb 7 2015/01/23 11:56:58
