Panasonic S-36MM1E5

3 - 2
2WAY SYSTEM
Outdoor Unit Repair Procedures
3
1. Removing Panels
(1) Front panel removal (Fig. 1)
• Remove the front panel.
Be sure to turn off the power before maintenance. When the power is turned off,
wait for 5 minutes without any work. Then start working.
CAUTION
Power outlet panel
Tubing cover
Front panel
Front panel
Type 8HP / 10HP / 12HP
Fig. 1-a
Front panel
Power outlet panel
Tubing cover
Front panel
Type 14HP / 16HP
Fig. 1-b
Left front panel
Right front panel
Upper left front panel
Lower right
front panel
Power outlet panel
Tubing cover
Type 18HP / 20HP
Fig. 1-c
