2 - 9
2WAY SYSTEM
Control Functions - Indoor Unit
2
9. Automatic Flap Control
10. Filter Sign
9. Automatic Flap Control
The flap position can be selected from 5 positions.
Operating mode Flap position
Cooling/Dry F1・F2・F3
Fan F1・F2・F3・F4・F5
Heating F1・F2・F3・F4・F5
① The flap moves to the following position automatically when the indoor unit is stopped.
F0 (close): Types K1, K2, T1, D1, U1, Y1, Y2
F5: Models other than the above
② The flap closes once and moves to the set position when the operating mode is changed.
※ If the flap position cannot be adjusted because of a problem, only the swing operation can be
used. Check the flap and flap motor.
※ The swing operation can be set for the flap.
10. Filter Sign
① When accumulated operating time of the indoor unit reaches the set time, the filter sign appears on
the remote controller. Clean the filter.
See pages 5-10.
② After cleaning the filter, press the filter button on the remote controller once. The filter sign turns off.
F1
F2
F3
F4
F5
F0
SM830204-05_2WAY SYS.indb 9 2015/01/21 17:00:34
