2WAY SYSTEM
Remote Controller Functions
5 - 11
2. Detailed Settings Function
5
2. Detailed Settings Function
List of Detailed Setting Items
Item code
Item
.oN.oN.oN
Setting data
Description DescriptionDescription
0001
2-Way Cassette (L1)
Type
Indoor unit
capacity
0003
0009
0012
0017
0021
0001 Unit No. 1
0002 Unit No. 2
0003 Unit No. 3
0030 Unit No. 30
System
address
0099 Not set
0001 Unit No. 1
0002 Unit No. 2
0003 Unit No. 3
0064 Unit No. 64
Indoor unit
address
0099 Not set
0000 Individual (1:1 = Indoor unit with no group wiring)
0001 Main unit (One of the group-control indoor units)
0002 Sub unit (All group-control indoor units except for main unit)
Group control
address
0099 Not set
010
Shifts intake temperature 10°C down.
009
Shifts intake temperature 9°C down.
001
Shifts intake temperature 1°C down.
0000 No intake temperature shift
0001
Shifts intake temperature 1°C up.
0009
Shifts intake temperature 9°C up.
Cooling
intake
temperature
shift
0010
Shifts intake temperature 10°C up.
0000 Function disabled
0001 Stops automatically 5 minutes after operation starts.
0002 Stops automatically 10 minutes after operation starts.
0123 Stops automatically 615 minutes after operation starts.
0124 Stops automatically 620 minutes after operation starts.
Automatic
stop time
after
operation
start
*Can be set
in 5-minute
units.
0125 Stops automatically 625 minutes after operation starts.
0005
0008
0006
0010
0002
0003
0011
0007
0037
High Static Pressure
Ducted (E1)
Floor Standing (P1)
1-Way Cassette (D1)
Ceiling (T1)
Slim Type Ducted (Z1)
Concealed Floor
Standing (R1)
0001
0007
0011
0015
0020
4-Way Cassette (60×60) (U1, Y1, Y2)
Low Silhouette Ducted (F1, F2)
Slim Low Static Ducted (M1)
Wall Mounted (K1, K2)
0010
0018
0005
0013
0038
63 (Type 60)
36 (Type 36)
160 (Type 160)
0023 280 (Type 280)
90 (Type 90)
15 (Type 15)
71 (Type 73)
and S-71MR1E5
For S-71MP1E5
112 (Type 106)
180 (Type 180)
22 (Type 22)
45 (Type 45)
28 (Type 28)
56 (Type 56)
80 (Type 73)
and S-71MR1E5
Except S-71MP1E5
140 (Type 140)
224 (Type 224)
2WAY SYSTEM
Remote Controller Functions
<Procedure of CZ-RTC3>
CZ-RTC3
Fig. 5
1
Keep pressing the , and
buttons
simultaneously for 4 or more seconds.
The “Maintenance func” screen appears on the
LCD display.
2
Press the or button to see each
menu.
If you wish to see the next screen instantly, press
the or button.
Select “8. Detailed settings” on the LCD display
and press the button.
The “Detailed settings” screen appears on the
LCD display.
Select the “Unit no.” by pressing the or
button for changes.
Maintenance func
1. Outdoor unit error data
2. Service contact
3. RC setting mode
4.Test run
Sel. Page [ ] Confirm
20:30 (THU)
Maintenance func
5. Sensor info.
6. Servicing check
8. Detailed settings
Sel. Page [ ] Confirm
20:30 (THU)
7. Simple settings
Detailed settings
Unit no. Code no. Set data
103-1 0001
Sel. Next
20:30 (THU)
3
Select the “Code no.” by pressing the or
button.
Change the “Code no.” by pressing the or
button (or keeping it pressed).
4
Select the “Set data” by pressing the or
button.
Select one of the “Set data” by pressing the
or button.
Then press the button.
5
Select the “Unit no.” by pressing the or
button and press the button.
The “Exit detailed settings and restart?” (Detailed
setting-end) screen appears on the LCD display.
Select “YES” and press the button.
Detailed settings
Unit no. Code no. Set data
3-1 0001
Sel. Next
20:30 (THU)
10
Detailed settings
Unit no. Code no. Set data
3-1
Sel.
20:30 (THU)
10 0001
Detailed settings
Unit no. Code no. Set data
ALL
Sel. Next
20:30 (THU)
01 0002
Exit detailed settings
and restart?
NOYES
SM830231-00Single欧州.indb6 2014/04/0413:48:32
START
[ ]
20:30 (THU)
[ ] Confirm
