Ducted Type S-140PN1E5 / U-140PE1E8
INDOOR MODEL S-140PN1E5
OUTDOOR MODEL U-140PE1E8
Branch pipe MODEL -
PERFORMANCE TEST CONDITION ISO5151 / EN14825
POWER SUPPLY
ø, Hz 1ø 50Hz 3ø 50Hz
V 220 230 240 380 400 415 Min Max
C
O
O
L
I
N
G
CAPACITY
kW 14.0 14.0 14.0 3.3 15.5
BTU/h 47800 47800 47800 11300 52900
CURRENT A 1.89 1.82 1.74 6.95 6.60 6.35 - -
INPUT POWER
W 250 250 250 4.400k 4.400k 4.400k - -
TOTAL W - 4.650k 4.650k 4.650k 1000 6.200k
ANNUAL CONSUMPTION TOTAL W 4 - - 2325 - - -
EER/EER CLASS
TOTAL(W/W) 5/("A"~"G") - - - 3.01 3.01 / B 3.01 3.30 2.50
Erp
6
Pdsign kW ------
SEER (W/W) ------
Annual consumption kWh------
Class ------
POWER FACTOR % - - - 96 96 96 - -
NOISE INDOOR
(H/M/L)
dB-A 46/44/39 -
Power Level dB 67/65/60 -
NOISE OUTDOOR
(H/L)
dB-A 54/-
Power Level dB 71/-
H
E
A
T
I
N
G
CAPACITY
kW 16.0 16.0 16.0 4.1 18.0
BTU/h 54600 54600 54600 14000 61400
CURRENT A 1.89 1.82 1.74 7.00 6.65 6.45 - -
INPUT POWER
W 250 250 250 4.440k 4.440k 4.440k - -
TOTAL W - 4.690k 4.690k 4.690k 1050 6.100k
COP/COP CLASS
TOTAL(W/W) 5/("A"~"G") - - - 3.41 3.41 / B 3.41 3.90 2.95
Erp
6
Pdsign kW ------
Tbivalen °C ------
SCOP (W/W) ------
Annual consumption kWh------
Class ------
POWER FACTOR % - - - 96 96 96 - -
NOISE INDOOR
(H/M/L)
dB-A 46/44/39 - ⁄⁄
Power Level dB 67/65/60 -
NOISE OUTDOOR
(H/L)
dB-A - 55/- ⁄⁄
Power Level dB - 71/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 2.59/0.345k 2.53/0.345k 2.47/0.345k 11.0/6.800k 11.0/7.150k 11.0/7.450k ⁄
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 7.00/3.0k 6.65/3.0k 6.45/3.0k ⁄
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 200 90×2 ⁄
MOISTURE REMOVAL VOLUME L/h(Pt/h) 9.0 (18.9) -
External static pressure
Pa (mmAq) 50 (MIN10 - MAX80)
I/D AIR
FLOW
COOL m
3
/min (ft
3
/min) 40 (1413)
HEAT m
3
/min (ft
3
/min) 40 (1413)
O/D AIR
FLOW
COOL m
3
/min (ft
3
/min) 135 (4767)
HEAT m
3
/min (ft
3
/min) 120 (4238)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9) /
P
R
O
D
I
M
HEIGHT : H mm(inch) 250 (9-27/32) 1416 (55-3/4) /
WIDTH : W mm(inch) 1200 (+100) (47-1/4) (+3-15/16) 940 (37-1/32) /
DEPTH : D mm(inch) 650 (25-19/32) 340 (13-13/32) /
P
A
C
D
I
M
HEIGHT : H mm 338 1556 /
WIDTH : W mm 1402 1055 /
DEPTH : D mm 761 485 /
MASS
(NET) kg(lb) 41 98 /
(GROSS) kg(lb) 48 108 /
LAYERS LIMIT (actually) 6 (7) 1 (2)
Operation
Condition
Cool O.D(DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat O.D(DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0(16.4) fl ared type, 5.0(16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1) ~ ~
I/D&O/D HEIGHT DIFFERENCE m (ft) 15 (OD located lower) / 30 (OD located higher) (49.2/98.4)
ADD GAS AMOUNT g/m (oz/ft) 50 (537.6)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)
*1
:
In case it is necessary to indicate the air fl ow volume in (l/s), the value in (m
3
/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2
:
If the EUROVENT Certifi ed models can be operated under the “extra-low” temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage
230 V shall be used.
*3
:
Network Impedance shall be applicable for EUROPE and CHINA models.
*4
:
The annual consumption is calculated by multiplying the input power at 230 V (400 V) by an average of 500 hours per year in cooling mode.
*5
:
EER and COP classification is at 230 V (400 V) only in accordance with EU directive 2002/31/EC.
*6
:
SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season,
Other fiche data indicates in an attached sheet.
