Panasonic SA-AK48 - Replacement Parts List; Mechanical Assembly Parts

Notes:
• • Important safety notice :
Component identified
mark have special
characteristics important safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), hight-quality sound (capacitors),
low-noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
• • The <ODSD> mark in Remarks indicates source of
supply.
• • The marking (RTL) indicates thet Retention Time is
Limited for this item. After the discontinuation of this
assembly in production, the item will continue to be
available for a specific period of item. The retention
period of availability is dependent on the type of
assembly, and in accordance with the laws governing
part and product retention. After the end of this period,
the assembly will on longer be available.
• • [M] indicates in the remarks columns indicates parts
supplied by MESA.
Ref.
No.
Part No. Part Name & Description Psc. Remarks
CABINET AND CHASSIS
1 REEX0065-1 20P FFC 1 [M]
2 REEX0081 19P FFC WIRE 1 [M]
3 REEX0083 14P FFC WIRE 1 [M]
4 REEX0090 26P FFC 1 [M]
5 PFAK48 FRONT PANEL 1 [M]
6 RGU1847-H RANDOM BUTTON 1 [M]
7 RGU1855-H DEMO BUTTON 1 [M]
8 RGU1849-Q S. WOOFER BUTTOM 1 [M]
9 RGU1854B-H A1 BUTTON 1 [M]
10 RGU1851-H CONTROL BUTTON 1 [M]
11 RGL0487-Q LIGHTING CHIP 1 [M]
12 RGU1845-H POWER BUTTON 1 [M]
13 RGK1234-K EQ SHEET 1 [M]
14 RGL0489-Q CLOCK LIGHT 1 [M]
15 RGU1853-H CLOCK BUTTON 1 [M]
16 RGU1852-H DECK BUTTON 1 [M]
17 RKF0585-K2J CASS. HOLDER (L) 1 [M]
18 RKF0586-K2J CASS. HOLDER (R) 1 [M]
19 RKF0604-H CASSETTE LID (L) 1 [M]
20 RKF0605-H CASSETTE LID (R) 1 [M]
21 RKW0601-Q CASSETTE WINODW (L) 1 [M]
22 RKW0602-Q CASSETTE WINDOW (R) 1 [M]
23 RXG0049 DAMPER GEAR UNIT 2 [M]
24 RMB0474-1 CASS. OPEN SPRING 2 [M]
25 RKW0603-V1 FL WINDOW 1 [M]
26 RUS757ZAA CASSETTE HALF SPRING 4 [M]
27 RGK1233-Q JOG ORNAMENT 1 1 [M]
28 RGK1240-Q JOG ORNAMENT 2 1 [M]
29 RGK1238A-S JOG SHEET 1 [M]
30 RGU1848A-Q FUNCTION BUTTON 1 [M]
31 RMKX0036 BOTTOM CHASSIS 1 [M]
32 RYQ0289-S1 JOY UNIT 1 [M]
33 RMKX0038A CD HCASSIS 1 [M]
34 SHE187-4 SPACER (TRANS) 2 [M]
35 REM0072-3 FAN 1 [M]
36 RGRX2B0016-2 REAR PANEL 1 [M]
37 RMNX0029-4 SUB-TRANS HOLDER 1 [M]
38 RKMX2B0045-DBL TOP CABINET (BENT) 1 [M]
39 RGK1232-S CD LID 1 [M]
40 RGW0330A-S MAIN VOL KNOB 1 [M]
41 RGU1850A-Q DPL BUTTON 1 [M]
Ref.
No.
Part No. Part Name & Description Psc. Remarks
42 RYQ0290-S JOG CYLINDER UNIT 1 [M]
43 RGL0486-Q DISC LIGHTING CHIP 1 [M]
44 RGB0113-N PANA BADGE (HOOK TYP 1 [M]
45 RHD30002-H SCREW 6 [M]
46 RGU1846-H DISC BUTTON 1 [M]
47 RXXX0017-2 HEAT SINK UNIT 1 [M]
48 RMN0577 JOY CYLINDER BASE 2 [M]
49 RGLX0025-Q TRI-AMP LIGHT CHIP 1 [M]
50 RKA0059-K LEG RUBBER 1 [M]
51 RMNX0030 FL HOLDER 1 [M]
52 RMRX0030 HEAT SINK SUPPORT 1 [M]
53 RMNX0019 PCB SPACER 1 [M]
54 RGW0341-S MIC KNOB 1 [M]
55 XTW3+15T SCREW 4 [M]
56 XTB3+10JFZ SCREW 5 [M]
57 XTBS3+8JFZ1 SCREW 26 [M]
58 XTBS26+10J SCREW 20 [M]
59 XTB3+20J SCREW 2 [M]
60 XTW3+12T SCREW 4 [M]
61 XTB3+10J SCREW 2 [M]
62 RSC0027-2 TUNER PACK 1 [M]
CASSETTE DECK
101 RED0050 R/P HEAD BLOCK UNIT 1 [M]
101-1 RHE5152ZB SCREW 2 [M]
102 RED0051 P/B HEAD BLOCK UNIT 1 [M]
102-1 RHE5152ZB SCREW 2 [M]
103 RDG0300 REEL BASE GEAR 4 [M]
104 RDG0301 WINDING RELAY GEAR 2 [M]
105 RDK0026 MAIN GEAR 2 [M]
106 RDR0029 RELAY PULLEY 1 [M]
107 RDV0033-4 WINDING BELT 2 [M]
108 RDV0034-1 CAPSTAN BELT ´A´ 1 [M]
109 RDV0057 MAIN BELT B 1 [M]
110 RMB0312 TRIGGER LEVER SPRING 2 [M]
111 RMB0400 REEL SPRING 4 [M]
112 RMB0403 HEAB PANEL SPRING 2 [M]
113 RMB0404 BRAKE ROD SPRING 2 [M]
114 RMB0406 FR LEVER SP 2 [M]
115 RMB0408 THRUST SPRING 2 [M]
116 RML0370 TRIGGER LEVER 2 [M]
117 RML0371 FR LEVER 2 [M]
118 RML0372 WINDING LEVER 2 [M]
119 RML0374 EJECT LEVER 2 [M]
120 RMM0131 BRAKE ROD 2 [M]
121 RMM0133-1 EJECT ROD 2 [M]
122 RMQ0519 REEL HUB 4 [M]
123 RMS0398-1 MOVING CORE 2 [M]
124 RSJ0003 PLUNGER 2 [M]
125 RMC0061 PACK SPRING 2 [M]
126 RXF0061 FLYWHEEL ´F´ ASS´Y 2 [M]
127 RXF0062 FLYWHEEL ´R´ ASS´Y 2 [M]
128 RXG0040 FF RELAY GEAR ASS´Y 2 [M]
129 RMK0283A-J SUB CHASSIS 2 [M]
130 RXL0124 PINCH ROLLER ´F´ ASS 2 [M]
130-1 RMB0401 PINCH ARM SPRING ´F´ 2 [M]
131 RXL0125 PINCH ROLLER ´R´ ASS 2 [M]
131-1 RMB0402 PINCH ARM SPRING ´R´ 2 [M]
132 RXL0126 WINDING ARM ASS´Y 2 [M]
133 RXQ0412 HEAD PANEL ASS´Y 2 [M]
133-1 RMB0405 FR ROD SPRING 2 [M]
133-2 RMM0132 FR ROD 2 [M]
134 REM0088 CAP MOTOR ASS´Y 1 [M]
135 RHD26022 MOTOR SCREW 2 [M]
136 XTW2+5L HEAD BLOCK UNIT SCRE 4 [M]
137 XTW26+10S SUB-CHASSIS SCREW 6 [M]
138 XYC2+JF17 PCB EARTH SCREW 2 [M]
139 RFKJXED70-K CHASSIS ASS´Y 1 [M]
21 Replacement Parts List
83
SA-AK48
