9.3 Cassette Mechanism Test (For error code
H01, H02, H03, F01, F02)
TOP PREVIOUS NEXT
1.Press “TAPE, DECK 1/2” to select Deck 2.
2.Load a normal cassette tape with the erasure prevention tab, remove from left side only and
close the cassette holder.
3.Press “FAST FORWARD MEMORY” (Tape will not move).
4.Load a normalm, Cr02, metal cassette tape with the erasure prevention tab, remove from right
side only and close the cassette holder.
5.Press “REVERSE FM MODE/BP” (Tape will be stop after 2 seconds)
6.Load a pre-recorded tape with both side record tabs intact and close the cassette holder.
7.Press “PLAY/TUNE/TIME ADJ UP” (After TPS function, tape will stop automatically)
8.Press “REC/STOP” (Tape will not move)
9.Press “STOP/TUNE MODE” to indicate Error code.
¡ If several problem exist, error code will change each time when “ /TUNE MODE” is
pressed.
(e.g. H01 → H03 → F01 .....etc.)
10.Press “TAPE, DECK 1/2” to select Deck 1.
11.Repeat step 2 to 9 to test Deck 1. (Tape Deck 1 will not check H02 because of no recording
function)
