S. Virtualizer switch
S912
CD Open/Close switch
S971
Mode switch
S972
Half switch
S973
CR02 switch
S975
Recinh_F switch
VR900
Volume VR
- The voltage value and waveforms are the reference voltage of this
unit measured by DC electronic voltmeter (high impedance) and
oscilloscope on the basis of chassis. Accordingly, there may arise
some error in voltage values and waveforms depending upon the
internal impedance of the tester or the measuring unit.
No mark
: Playback
<< >>
: Rec
(( ))
: CD
< >
: FM
( )
: AM
- Importance safety notice :
Components identified by mark have special characteristics
important for safety. Furthermore, special parts which have
purposes of fire-retardant (resistors), high-quality sound
(capacitors), low-noise (resistors), etc. are used. When replacing
any of components, be sure to use only manufacturer's specified
42
