Panasonic SA-PM10 - Page 55

Pin No. Mark I/O Function
29 MLD O CD Signal Processor
Ctrl Load
30 SD I/O Tuner Signal Detect
31 PL_H O Deck Plunger
32 CD_RST O CD RST Output
33 HALT I AC Failure Detect Signal
34 RMT_IN I Remote Control Input
35 BLKCK I CD Subcode BLK CLK
36
CD_OPEN_SW
I CD Open Switch
37 STAT I CD Status Input
38 Rest_Sw I CD limit sw input for
the most inner point
39 VDD - VDD (+5V)
40 VREF+ - Vref (+5V)
41 KEY1 I Key input 1
42 KEY2 I Key input 2
43 VOL_JOG I Volume jog A_D
detection input
44 REGION I Region Setting Input
45 AN4 I MODE and TPS
46 BP O Beat Proof for AM
47 PDET I Power Supply Vol
Detect
48 AN7 I Half and RECINF
49 VREF(-) - Vref (-)
50 REC_H O Deck Rec Control O/P
51 Dimmer O Dimmer for LCD
52 SP_CLK/
E_CLK
O Sound Processor Serial
Clk
53 SP_DATA/
E_DATA
O Sound Processor Serial
Data/
EEPROM Data
54 CD_OPEN O CD Open Output
55 CD_CLOSE O CD Close Output
56 E_CS O EEPROM Chip Select
57 MOTOR_H O Deck Motor Control O/P
58 PHOTO_1 I Deck Photo SW Input
59~96
SEG37~SEG0
- Segment Driver
97 COM3 - Segment Driver
98 COM2 - Segment Driver
99 COM1 - Segment Driver
100 COM0 - Segment Driver
