Caution:
- Pb free solder has a higher melting point than standard solder;
Typically the melting point is 50 - 70°F (30 - 40°C) higher. Please
use a high temperature soldering iron. In case of soldering iron
with temperature control, please set it to 700 ± 20°F (370 ± 10°C).
- Pb free solder will tend to splash when heated too high (about
1100°F/600°C).
- When soldering or unsoldering, please completely remove all of
the solder on the pins or solder area, and be sure to heat the
soldering points with the Pb free solder until it melts enough.
6. Handling Precautions For Traverse Deck
The laser diode in the traverse deck (optical pickup) may break down due to potential difference
caused by static electricity of clothes or human body.
So, be careful of electrostatic breakdown during repair of the traverse deck (optical pickup).
Handling of CD traverse deck (optical pickup)
1. Do not subject the traverse deck (optical pickup) to static
electricity as it is extremely sensitive to electrical shock.
2. The short land between the No.4 (LD) and No.5 (GND) pins on the
flexible board (FFC) is shorted with a solder build-up to prevent
damage to the laser diode.
3. Take care not to apply excessive stress to the flexible board (FPC
board).
4. Do not turn the variable resistor (laser power adjustment). It has
already been adjusted.
6
