Ref. No. Part No. Part Name & Description Remarks
OSCILLATORS
X2 RLFDFT13DD CERAMIC FILTER [M]
X3 RSXD7M20C01 CRYSTAL OSCILLATOR [M]
X701 H2A169500009 CERAMIC OSCILLATOR [M]
X801 H0H433400001 CRYSTAL OSCILLATOR [M]
X900 RSXD32K7S02 CRYSTAL OSCILLATOR [M]
X901 RSXZ6M00D01T 6MHZ RESONATOR [M]
FUSES
F600 K5Y630B00001 FUSE
[M]
FUSE HOLDERS
FC600 EYF52BC FUSE HOLDER [M]
FC601 EYF52BC FUSE HOLDER [M]
FUSE PROTECTOR
FP351 K5G502AA0003 FUSE PROTECTOR
[M]
JACKS
JK1 RJH8304N JK ANTENNA [M]
JK500 K2HC107A0003 JK HEADPHONE [M]
JK501 K4BC04B00046 JK SPEAKER TERMINAL [M]
JK600 K2AA2B000004 JK AC INLET [M]
EARTH TERMINAL
E301 SNE1004-2 EARTH TERMINAL [M]
WIRES
W308B RWJ0102095SS 2P DECK-CASS EJECT [M]
W504B RWJ1105165XX 5P POWER/PHONE [M]
W505A REXV0006 9P POWER TO TRANS [M]
W900 RWJ1111138XX 11P PANEL-DECK [M]
W1903 RWJ0102050KR MOTOR WIRE [M]
RESISTORS
R2 ERDS2TJ472T 4.7K 1/4W [M]
R3 ERDS2TJ101T 100 1/4W [M]
R4 ERDS2TJ103T 10K 1/4W [M]
R5 ERDS2TJ471T 470 1/4W [M]
R6 ERDS2TJ474T 470K 1/4W [M]
R7 ERDS2TJ331T 330 1/4W [M]
R8 ERDS2TJ474T 470K 1/4W [M]
R9 ERDS2TJ331T 330 1/4W [M]
R10 ERDS2TJ562T 5.6K 1/4W [M]
R11 ERDS2TJ391T 390 1/4W [M]
