Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEX0097 19P (CR100 TO MAIN) [M]
3 RGKX0083A-H FRONT ORNAMENT [M]
4 RGKX0084-H UNDER ORNAMENT [M]
5 RGKX0085-H CD ORNAMENT [M]
6 RGKX0086-S CD LID [M]
7 RGKX0087-H CASS.ORNAMENT [M]
8 RGKX0088-S SENSOR PANEL [M]
9 RGKX0089-S VOLUME KNOB RING [M]
10 RGKX0091-S FUNCTION RING [M]
11 RGLX0037-A LCD WINDOW [M]
12 RGLX0038 LCD LIGHTING PANEL [M]
13 RGLX0039 LIGHTING CHIP [M]
14 RGLX0040 EDGE LIGHTING PANEL- [M]
15 RGLX0041 EDGE LIGHTING PANEL- [M]
16 RGPX0047 LCD SHEET [M]
17 RGPX0048 LCD DIFFUSER [M]
18 RGUX0404-S FUNCTION/STOP BUTTON [M]
19 RGUX0405-S POWER BUTTON [M]
20 RGUX0406-S DISP/DEMO BUTTON [M]
21 RGUX0407-S REC/TAPE EJECT BTN [M]
22 RGUX0408-S CD EJECT BUTTON [M]
23 RGWX0059-S VOLUME KNOB [M]
24 RHD30007-S SCREW [M]
25 RHDX20001-S SCREW [M]
26 RKA0059-K LEG FELT [M]
27 RKFX0090-S CASS LID [M]
28 RKMX0062-S FRONT PANEL [M]
29 RKMX0063-S TOP CABINET (BENT) [M]
30 RFKHAPM25GDS REAR CABINET ASS’Y [M]
31 RMEX0013 CASS LID SPRING [M]
32 RMKX0052 BOTTOM CHASSIS [M]
33 RMN0091 SPACER [M]
34 RMNX0049-W LCD HOLDER [M]
35 RMNX0050 TR2 SUPPORT BRACKET [M]
36 RMNX0051-W EDGE LIGHTING LED HO [M]
37 RMNX0053 PCB SPACER [M]
38 RMNX0055 SENSOR HOLDER [M]
39 RMRX0032-W TR2 CHASSIS [M]
40 RMVX0057 LCD LED COVER [M]
41 RSCX0055 TUNER SHIELD [M]
42 RSCX0056 TUNER SHIELD - RIGHT [M]
43 RXXX0027 HEATSINK UNIT [M]
44 XTB3+10JFZ SCREW [M]
45 XTB3+8JFZ SCREW [M]
46 XTBS26+10J SCREW [M]
47 XTV3+10F SCREW (HEAT SINK) [M]
48 XTV3+10G SCREW [M]
17.4. Component Parts List
50
