24.3.2. Cabinet Part List
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0026 21P FFC [M]
2 REEV0027 26P FFC [M]
3 REEV0039 17P FFC [M]
4 REEX0166 14P FFC WIRE [M]
5 REM0094A COOLING FAN [M]
6 RGK1750-S VOLUME RING [M]
7 RYPV0034-S FRONT PANEL UNIT [M]
7-1 RYQV0014-S CD LID UNIT [M]
7-2 RYQV0015-S BUTTON UNIT [M]
7-3 RHGV0008 LEG CUSHION [M]
7-4 RGUV0063-S CD/MAIN SEL. BUTTON [M]
7-5 RGK1756-A M/FUNCTION BTN ORN. [M]
8 RGL0660-Q1 VOLUME RING LIGHT [M]
9 RKSX0056Q-H REAR PANEL [M]E
9 RKSX0056Q-K REAR PANEL [M]EG
9 RKSX0056R-K REAR PANEL [M]EB
10 RGU2280-S CASS EJECT BUTTON [M]
11 RGW0406-S VOLUME KNOB [M]
12 RHD30007-K1 SCREW [M]
13 RKF0688-S CASS LID [M]
14 RKM0502A-K SIDE PANEL LEFT [M]
15 RKM0503A-K SIDE PANEL RIGHT [M]
16 RKM0504C-S TOP CABINET [M]
17 RMB0448-J LOCK ROD SPRING [M]
18 RMK0595 BOTTOM CHASSIS [M]
19 RMKX0090 INNER CHASSIS [M]
20 RMM0163-1 CASS LOCK ROD [M]
21 RMN0780 CD LID SUPPORT [M]
22 RMN0778 MD HOLDER [M]
23 RMNV0015 FL HOLDER [M]
24 RMN0779 LED HOLDER [M]
25 RMN0789 FUNCTION LED CASE [M]
26 RMQ1294 JOG BASE B [M]
27 RMR1619-W DIFFUSER CASE [M]
28 RMY0260 HEAT SINK (SMALL) [M]
29 RSC0725 EARTH PLATE [M]
30 RSCV0018 FL REAR SHIELD [M]
31 RSCV0019 REAR SHIELD PLATE [M]
32 RUS757ZAA CASS HALF SPRING [M]
33 RXGX0003 DAMPER GEAR [M]
34 RXXX0043 HEAT SINK UNIT [M]
35 RYQ0488-S JOG UNIT [M]
36 XTB3+10JFZ SCREW [M]
37 XTB3+8JFZ SCREW [M]
38 XTBS26+10J SCREW [M]
39 XTV3+10G-M SCREW [M]
40 XTW3+15T SCREW [M]
41 XTWS26+10Q SCREW [M]
42 XTWS3+6T SCREW [M]
43 RMB0782 EARTH SPRING [M]
44 RMB0780 CASS OPEN SPRING [M]
45 RSCV0021 EARTH PLATE [M]
115
SA-PM29E / SA-PM29EB / SA-PM29EG
