Panasonic SA-PM29E - 24.4 Electrical Part List

Ref.
No.
Part No. Part Name & Description Remarks
PRINTED CIRCUIT BOARD
REPX0363A CD SERVO (SIDE A AND SIDE B)
P.C.B.
[M] RTL
REPV0019A MAIN P.C.B. / PANEL P.C.B. /
TACT SWITCH P.C.B. / SWITCH
P.C.B. / HEADPHONE P.C.B. /
SPEAKER TERMINAL P.C.B.
[M] RTL
REPX0411A DECK P.C.B. / TAPE EJECT
P.C.B.
[M] RTL
REPX0321C DECK MECHANISM P.C.B. [M] RTL
REP3569A CD LOADING P.C.B. [M] RTL
REPV0018F POWER P.C.B. / TRANSFORMER
P.C.B.
[M] RTL
(E/EG)
REPV0018H POWER P.C.B. / TRANSFORMER
P.C.B.
[M] RTL
(EB)
INTEGRATED CIRCUITS
IC11 C0GAG0000007 IC DRIVER [M]
IC21 C0GAG0000007 IC DRIVER [M]
IC300 C1BB00000757 IC ASP [M]
IC301 C3FBHA000004 IC FLASH MEMORY [M]
IC302 C2CBJG000409 IC MICRO PROCESSOR [M]
IC304 C1BB00000715 IC RDS [M]
IC500 RSN314H41A-P IC POWER AMP HIC [M]
IC501 C0AABB000125 IC OP AMP [M]
IC503 C0CAABE00006 IC 3.3V REGULATOR [M]
IC601 C0HBB0000039 IC FL DRIVER [M]
IC602 C0HBB0000039 IC FL DRIVER [M]
IC701 AN22004A-NF IC HEAD AMP [M]
IC702 MN6627931BL IC LSI [M]
IC703 BA5948FPE2 IC 4 CH DRIVE [M]
IC704 C3ABMB000027 IC 16M DRAM [M]
IC971 CNB13030R2AU IC PHOTO INTERUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SW [M]
IC1001 AN7326K IC DECK R/P [M]
TRANSISTORS
Q1 B3NAA0000068 TRANSISTOR [M]
Q200 KRA102STA TRANSISTOR [M]
Q201 KTC3875GRTA TRANSISTOR [M]
Q222 KTC3875GRTA TRANSISTOR [M]
Q223 KTC3875GRTA TRANSISTOR [M]
Q224 KTC3875GRTA TRANSISTOR [M]
Q301 KTA1504GRTA TRANSISTOR [M]
Q302 KRC102STA TRANSISTOR [M]
Q303 KTA1504GRTA TRANSISTOR [M]
Q304 B1GBCFGG0001 TRANSISTOR [M]
Q305 B1GBCFGG0001 TRANSISTOR [M]
Q306 KRC103STA TRANSISTOR [M]
Q307 KTC3875GRTA TRANSISTOR [M]
Q308 KTC3875GRTA TRANSISTOR [M]
Q309 KRC101STA TRANSISTOR [M]
Q310 KRC101STA TRANSISTOR [M]
Q390 B1GBCFGG0001 TRANSISTOR [M]
Q400 KRA102STA TRANSISTOR [M]
Q422 KTC3875GRTA TRANSISTOR [M]
Q423 KTC3875GRTA TRANSISTOR [M]
Q424 KTC3875GRTA TRANSISTOR [M]
Q501 KTC2026 TRANSISTOR [M]
Q502 KTA1046 TRANSISTOR [M]
Q505 KTA1267GRTA TRANSISTOR [M]
Q506 KTA1046 TRANSISTOR [M]
Q508 KTC3199GRTA TRANSISTOR [M]
Q509 KRA110MTA TRANSISTOR [M]
Q514 2SD0592ARA TRANSISTOR [M]
Q515 KTC3199GRTA TRANSISTOR [M]
Q516 KTC3199GRTA TRANSISTOR [M]
Q517 KTC32030YTA TRANSISTOR [M]
Q519 B1AAGC000006 TRANSISTOR [M]
Q520 KTC2026 TRANSISTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
Q575 B1AAGC000006 TRANSISTOR [M]
Q577 2SC3940ARA TRANSISTOR [M]
Q578 KRC102MTA TRANSISTOR [M]
Q579 2SB0621AHA TRANSISTOR [M]
Q600 KRC119STA TRANSISTOR [M]
Q601 KRC119STA TRANSISTOR [M]
Q602 KRC119STA TRANSISTOR [M]
Q603 KRC119STA TRANSISTOR [M]
Q604 KTC3875GRTA TRANSISTOR [M]
Q700 B1AACF000063 TRANSISTOR [M]
Q701 2SA1037AKSTX TRANSISTOR [M]
Q701 KTA12710YTA TRANSISTOR [M]
Q702 B1AACF000063 TRANSISTOR [M]
Q703 B1AACF000063 TRANSISTOR [M]
Q704 KRA102MTA TRANSISTOR [M]
Q710 B1AAGC000006 TRANSISTOR [M]
Q711 B1AAGC000006 TRANSISTOR [M]
Q714 KTC3199GRTA TRANSISTOR [M]
Q715 KTC3199GRTA TRANSISTOR [M]
Q716 KTC3199GRTA TRANSISTOR [M]
Q717 KTC3199GRTA TRANSISTOR [M]
Q718 B1AAGC000006 TRANSISTOR [M]
Q719 B1AAGC000006 TRANSISTOR [M]
Q720 KTC3199GRTA TRANSISTOR [M]
Q721 KTC3199GRTA TRANSISTOR [M]
Q722 KRA110MTA TRANSISTOR [M]
Q723 KTA12710YTA TRANSISTOR [M]
Q724 KTC3199GRTA TRANSISTOR [M]
Q725 B1AAGC000006 TRANSISTOR [M]
Q726 B1AAGC000006 TRANSISTOR [M]
Q1101 2SD2114K1V TRANSISTOR [M]
Q1201 2SD2114K1V TRANSISTOR [M]
Q1302 B1GDCFJJ0002 TRANSISTOR [M]
Q1303 B1GBCFGH0001 TRANSISTOR [M]
Q1304 B1GDCFGH0002 TRANSISTOR [M]
Q1306 B1ABCF000011 TRANSISTOR [M]
Q1307 B1ABCF000011 TRANSISTOR [M]
Q1309 B1AAGC000006 TRANSISTOR [M]
Q1310 B1AAGC000006 TRANSISTOR [M]
Q1312 B1ABCF000011 TRANSISTOR [M]
Q1314 B1GDCFGH0002 TRANSISTOR [M]
Q1315 KTA12710YTA TRANSISTOR [M]
Q1316 2SD09650RA TRANSISTOR [M]
Q1317 2SD2114K1V TRANSISTOR [M]
DIODES
D201 B0BC01000014 DIODE [M]
D302 1SS380TE-17 DIODE [M]
D303 1SS380TE-17 DIODE [M]
D304 MA729TX DIODE [M]
D305 B0ACCK000005 DIODE [M]
D306 1SS380TE-17 DIODE [M]
D307 1SS380TE-17 DIODE [M]
D308 1SS380TE-17 DIODE [M]
D500 B0EBNL000004 DIODE [M]
D505 B0AACK000004 DIODE [M]
D508 MTZJ15BTA DIODE [M]
D515 B0BA9R600002 DIODE [M]
D517 B0BA5R600016 DIODE [M]
D520 B0BA9R600002 DIODE [M]
D524 B0BA01100004 DIODE [M]
D525 B0AACK000004 DIODE [M]
D526 B0AACK000004 DIODE [M]
D527 B0AACK000004 DIODE [M]
D530 B0AACK000004 DIODE [M]
D531 B0BA8R200005 DIODE [M]
D578 B0EAKM000117 DIODE [M]
D579 B0EAKM000117 DIODE [M]
D580 B0EAKM000117 DIODE [M]
D581 B0EAKM000117 DIODE [M]
24.4. Electrical Part List
116
SA-PM29E / SA-PM29EB / SA-PM29EG
