Pin
No.
Mark I/O Function
34 CD_OPSW I/O
CD Tray Open Detect
SW
(H: OPEN; L: CLOSE)
35 CR TIMER I/O CR TIMER
36 SEL 1 I/O Function Change 1
37 SEL 2 I/O Function Change 2
38 /TUNER_L I/O Non-tuner Function L
39 DIGITAL_L I/O
Opt In Mute Control Out
(L: Digital in)
40 CD&
TUNER_H
I/O
“H”: CD and Tuner
Function
41 SPEED I/O
CD Highspeed
Recording
Corresponding Input H:
Highspeed
Correspondence)
42 AUX2_DATA
/ OUT
I/O P-MD Link .....Data Out
43 /SUBQAUX /
DATA
I/O
CD Subcode Data In
P-MD Link use Data In
44 SQCK I/O
CD Subcode Read
Clock Output
45 MD_DATAIN I/O
MD Data Output
(Input of MD unit)
46
MD_DATAOUT
I/O
MD Data Output
(Input of MD Unit)
47 MD_CLK I/O MD Clock Output
48 MD_REQ I/O MD Request Signal Out
49 MD_SYS RST I/O
MD Reset Output (L:
Reset)
50 LOADSW I/O
MD Loading SW Input (H
: SW Off)
51 (N.C) I/O N.C
52 SW1 I/O MD Panel SW
53 SW2 I/O CD Panel SW
54 SW3 I/O MD Shutter SW
55 ECLK I/O EEPROM Clock Output
56 ECS I/O EEPROM CS Output
57 EDATA I/O EEPROM Data In/Out
58 MUTE A I/O
Audio Mute Output (L:
Mute On)
59 PWRCONT I/O Power Control Output
60 /CD_L I/O Non-CD Function L
61 /STATUS I/O CD Status Input
