Panasonic SA-PM65MD - Page 59

Pin
No.
Mark I/O Function
62 CD RESET I/O CD Reset Output
63 /RESTSW I/O CD Traverse Limit SW
64 MCLK I/O CD LSI Command Clock
65 MDATA I/O CD LSI Command Data
66 MLD I/O CD LSI Command Load
67 CD_PNL_CL I/O Front Panel Close
Control(active H)
68 CD_PNL_OP I/O Front Panel Open
Control(active H)
69 MD_PNL_CL I/O Front Panel Close
Control(active H)
70 MD_PNL_OP I/O Front Panel Open
Control(active H)
71 LOPEN_L I/O
CD Tray Open Low
Speed
(active L)
72 LCLOSE_H I/O
CD Tray Close Low
Speed
(active H)
73 ACCNT I/O
Main Transformer
Control Output
(active H)
74 SD I/O Tuner Signal Detect
75 PLL DO I/O PLL Control Data Input
76 PLL DI I/O PLL Count Data Output
77 PLL CE I/O PLL Chip Enable Output
78 PLL CLK I/O PLL Clock Output
79 (N.C) I/O N.C
80
CLOD_START
/ _HSCM
I/O 74 minutes restriction
detect input at
CLOD_START (L:
restrict)
81 TMRLED I/O
Timer LED Control Out
(Timer Setting: L)
82 LED_CD I/O CD LED Drive(active L)
83 LED_MD I/O MD LED Drive(active L)
84 LED_TUNER I/O Tuner LED Drive(active
L)
85 (N.C) I/O (Open)
86 (N.C) I/O (Open)
87 AGCLK I/O ASP Clock Output
88 AGDATA I/O ASP Data Output
89 AGLATCH I/O ASP Latch Output
59
