Panasonic SC-AK100 User Manual

RQT6351-1P
P
CD Stereo System
Operating Instructions
Model No. SC-AK100
Before connecting, operating or adjusting this product, please read these
instructions completely.
Please keep this manual for future reference.
PC
As an ENERGY STAR
®
Partner, Panasonic has determined
that this product meets the ENERGY STAR
®
guidelines for
energy efficiency.
For U.S.A. only
The servicenter list and warranty can be found
on pages 15 and backcover.

Panasonic SC-AK100 Specifications

Amplifier Section

power output (60 Hz–16 kHz, both channels driven)	40 W per channel (6 Ω)
power output (1 kHz, both channels driven)	50 W per channel (6 Ω)
input sensitivity (AUX)	250 mV
input impedance (AUX)	13.3 kΩ

FM Tuner Section

frequency range (200 kHz steps)	87.9 – 107.9 MHz
frequency range (100 kHz steps)	87.5 – 108.0 MHz
sensitivity	2.5 µV (IHF)
S/N 26 dB	2.2 µV
antenna terminal	75 Ω (unbalanced)

AM Tuner Section

frequency range	520 – 1710 kHz (10 kHz steps)
sensitivity (S/N 20 dB at 1000 kHz)	560 µV/m

Cassette Deck Section

track system	4 track, 2 channel
record/playback head	Solid permalloy head
erasure head	Double gap ferrite head
motor	DC servo motor
recording system	AC bias 100 kHz
erasing system	AC erase 100 kHz
tape speed	4.8 cm/s (1[7]/8 ips)
overall frequency response (NORMAL TYPE I)	35 Hz – 14 kHz
S/N	50 dB (A weighted)
wow and flutter	0.18% (WRMS)
fast forward and rewind time	Approx. 120 seconds with C-60 cassette tape

CD Section

sampling frequency	44.1 kHz
decoding	16 bit linear
beam source/wavelength	Semiconductor laser/780 nm
number of channels	Stereo
frequency response	20 Hz–20 kHz (+1, –2 dB)
wow and flutter	Below measurable limit
digital filter	8 fs
D/A converter	MASH (1 bit DAC)

Speaker Section

type	2 way speaker system
woofer	10 cm (4˝) cone type
super tweeter	Piezo type
impedance	6 Ω
input power	80 W (Music)
output sound pressure level	86 dB/W (1.0 m)
cross over frequency	10 kHz
frequency range	54 Hz–19 kHz (–16 dB), 75 Hz–17 kHz (–10 dB)
dimensions (WxHxD)	190 x 315 x 190 mm (7[15]/32˝ x 12[13]/32˝ x 7[15]/32˝)
mass	2.4 kg (5.3 lb.)

General

power supply	AC 120 V, 60 Hz
power consumption	120 W
standby power consumption	Approx. 0.49 W
dimensions (WxHxD)	250 x 315 x 345 mm (9[27]/32˝ x 12[13]/32˝ x 13[19]/32˝)
mass	6.4 kg (14.1 lb.)
