Panasonic SC-HC17 User Manual

ENGLISHENGLISH
RQT9678
10
10
Amplifier section
RMS output power stereo mode
Front Ch (both ch driven)
5 W per channel (6
), 1 kHz, 10% THD
Total RMS stereo mode power 10 W
Tuner section
Preset station FM 30 stations
Frequency modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75
(unbalanced)
Terminals section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
USB port power 500 mA (max)
Headphones jack
Terminal Stereo, 3.5 mm jack
Disc section
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3
)
Pick up
Wavelength 790 nm (CD)
Laser power CLASS I
NORSK
Bølgelengde 790 nm (CD)
Laserstyrke Ingen farlig stråling sendes ut
(med sikkerhets-beskyttelse)
Audio output (Disc)
Number of channels 2 ch (FL, FR)
FL = Front left channel
FR = Front right channel
MPEG-1 Layer 3, MPEG-2 Layer 3
Speaker section
Type 1 way, 1 speaker system (bass reflex)
Speaker unit(s)
Full range 8 cm cone type x 1/ch
Impedance 6
General
Power supply AC 220 to 240 V, 50 Hz
Power consumption 12 W
Dimensions (W x H x D) 400 mm x 213 mm x 110 mm
[D = 72 mm (min)]
Mass 1.9 kg
Operating temperature range 0°C to +40°C
Operating humidity range
35% to 80% RH (no condensation)
Power consumption in standby mode
0.2 W (approximate)
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyzer.
Specifications
HC17_EC1_1en.indd 10HC17_EC1_1en.indd 10 5/16/2012 4:52:07 PM5/16/2012 4:52:07 PM

Panasonic SC-HC17 Specifications

General

Karaoke	No
Bass reflex	Yes
Speaker type	1-way
RMS rated power	10 W
Number of speakers	2
Type	-
Product color	Black
Disc loading type	Front
Number of optical discs	1 discs
Playback disc formats	CD audio, SACD
Tuner type	Digital
Supported radio bands	FM
Preset stations quantity	30
Display type	FLT
Apple docking compatibility	Not supported
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Equalizer bands quantity	5
Power source	AC
Input voltage	220-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	12 W

Weight and Dimensions

Depth	110 mm
Width	400 mm
Height	213 mm
Weight	2000 g
