Overview of controls
A Standby/on switch [`], [1]
• Press to switch the unit from on to standby mode or
vice versa. In standby mode, the unit is still consuming
a small amount of power.
B Select audio source
C Basic playback control
D View the clock and timer options
E View information
F Select the sound effects
G Select the option
Skip album
H Set the sleep timer
I Decrease the brightness of the display panel
• Press the button again to cancel.
J Adjust the volume of the system
K Mute the sound of the system
• Press the button again to cancel.
• “MUTE” is also cancelled when you adjust the volume
or when you switch off the system.
L View the play menu
View the radio options
M USB port ( )
N Headphones jack ( )
• Plug type: Ø 3.5 mm stereo (not supplied)
• Avoid listening for prolonged periods of time to prevent
hearing damage.
• Excessive sound pressure from earphones and
headphones can cause hearing loss.
• Listening at full volume for long periods may damage
the user’s ears.
O Open or close the sliding door
P Sliding door
Q Remote control sensor
• Maximum range: 7 m directly in front
R Display panel
Remote control
MUTESETUP
SOUND
ALBUM
PLAY MENU
DISPLAY
SLEEP
USB
CD
DIMMER
OK
RADIO
Main unit
Top view
AB OJC
NM
P Q R
Front view
