Panasonic SC-HC17 User Manual

ENGLISH
ENGLISH
RQT9678
5
5
Disc, USB
Inserting or removing media
Disc
Press [CD x OPEN/CLOSE] on the main unit to open the
sliding door.
Put in a disc with the label facing towards you.
Note:
Keep fingers away from the sliding door when it is closing.
USB
Note:
Do not use a USB extension cable. The system cannot
recognise USB device connected through a cable.
Click!
USB device
(not supplied)
Getting started
1 Connect the FM indoor antenna.
Place the antenna where reception is best.
2 Connect the AC mains lead.
Power consumption in standby mode: 0.2 W
(approximate)
Do not use an AC mains lead from other equipment.
Note:
• Some settings return to default when you disconnect the
system.
• These speakers do not have magnetic shielding. Do
not put them near TVs, PCs or other equipment easily
influenced by magnetism.
• You cannot remove the net of the speakers.
Preparing the remote control
Before using
Replacing the battery
Replace with a new battery (CR2025 lithium battery).
1 While pressing the stopper, pull out the battery
holder.
2 Insert a new battery with the (+) side facing up.
3 Push the battery holder back fully.
Tape
To household mains socket
Insulation sheet
CR2025
HC17_EC1_1en.indd 5HC17_EC1_1en.indd 5 5/16/2012 4:52:05 PM5/16/2012 4:52:05 PM

Panasonic SC-HC17 Specifications

General

Karaoke	No
Bass reflex	Yes
Speaker type	1-way
RMS rated power	10 W
Number of speakers	2
Type	-
Product color	Black
Disc loading type	Front
Number of optical discs	1 discs
Playback disc formats	CD audio, SACD
Tuner type	Digital
Supported radio bands	FM
Preset stations quantity	30
Display type	FLT
Apple docking compatibility	Not supported
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Equalizer bands quantity	5
Power source	AC
Input voltage	220-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	12 W

Weight and Dimensions

Depth	110 mm
Width	400 mm
Height	213 mm
Weight	2000 g
