13
TQBJ2134
Specifications
█
General
Dimensions (W x H x D) 400 mm x 197 mm x 107 mm
Mass 1.9 kg
Operating temperature range 0°C to +40°C
Operating humidity range
35% to 80% RH (no condensation)
█
Amplifier section
RMS output power stereo mode
Front Ch (both ch driven)
10 W per channel (8 Ω), 1 kHz, 10% THD
Total RMS power 20 W
PMPO output power 200 W
█
Tuner, terminals section
Preset memory FM 30 stations
[For Australia and New Zealand AM 15 stations
Frequency modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 Ω (unbalanced)
For Australia and New Zealand
Amplitude modulation (AM)
Frequency range 522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
█
Disc section
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3
2
)
Pick up
Wavelength 790 nm (CD)
█
USB section
USB port power WDC OUT 5 V 500 mA
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
Audio support format MP3
2
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz
Audio word size 16 bits
Channel count 2 ch
USB device file system FAT12, FAT16, FAT32
█
Bluetooth
®
section
Version Bluetooth
®
Ver. 2.1 + EDR
Class Class 2
Supported profiles A2DP, AVRCP
Frequency band 2.4 GHz band FH-SS
Operation distance 10 m line of sight
Supported codec SBC
█
Speaker section
Speaker unit(s)
Full range 8 cm cone type x 2
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyser.
1
No device is connected to the USB port before switching to
standby mode.
2
MPEG-1 Layer 3, MPEG-2 Layer 3
Power supply
[For Australia and New Zealand AC 220 V to 240 V, 50 Hz
[For Asia AC 110 V to 240 V, 50/60 Hz
Power consumption
14 14 W
Power consumption in standby mode
1
(approximate)
With “BLUETOOTH STANDBY” set to “OFF” 0.2 W
With “BLUETOOTH STANDBY” set to “ON” 0.3 W
HC200.GN.GA TQBJ2134 En.fm Page 13 Monday, February 12, 2018 3:57 PM
