Headphones (not included)
■ Use
Aim at the sensor, avoiding obstacles, at a maximum
range of 7 m directly in front of the unit (Exact
distance depends on angles).
Operation can be affected by strong light sources,
such as direct sunlight, and the glass doors on
cabinets.
•
•
■ Batteries
Use a manganese dry battery or an alkaline dry battery.
Insert so the poles (+ and – ) match those in the remote
control.
Remove if the remote control is not going to be used for
a long period of time.
Store in a cool, dark place.
Do not heat or expose to flame.
Do not leave the batteries in an automobile exposed to
direct sunlight for a long period of time with doors and
windows closed.
Mishandling of batteries in the remote control can cause
electrolyte leakage, which may cause a fire.
•
•
•
•
•
•
•
Preparing the remote control
Connections (continued)
Remote control
signal sensor
R6/LR6, AA
Place this side in before the other side
Optional antenna connections
Never use an outdoor antenna during a lightning storm.
You can connect the FM outdoor antenna for better reception.
Please consult your dealer for installation.
Disconnect the FM indoor antenna if an FM outdoor antenna is installed.
Connect the AM outdoor antenna without removing the AM loop antenna.
Run 5 to 12 m of vinyl-covered wire horizontally along a window or other convenient location.
•
•
•
•
FM outdoor antenna
75 Ω coaxial cable
(not included)
FM outdoor antenna (not included)
AM outdoor antenna
Demo function
When the unit is first plugged in, a demonstration of its
functions may be shown on the display.
If the demo setting is off, you can show a demonstration
by selecting “DEMO ON”.
Press and hold [g, –DEMO].
The display changes each time the button is held down.
While in standby mode, select “DEMO OFF” to reduce
power consumption.
DEMO OFF DEMO ON
[g, –DEMO]
