12
RQT9922
Place the infrared emitter in sight of the TV’s remote control signal
sensor.
≥ For the location of the TV’s remote control signal sensor, refer to the operating instructions for the TV.
Aim the TV’s remote control at this system’s remote control sensor and
operate the TV.
≥ For the location of this system’s remote control signal sensor, refer to page 8.
≥ Make sure to clean the surface, where the adhesive tape is to be attached.
≥ If you peel off the adhesive tape, the surface may become damaged and exposed adhesive may remain. Once you have
confirmed the TV is operating correctly, secure it by attaching the adhesive tape.
≥ The supplied IR Blaster is only compatible with Panasonic TVs.
∫ Placement example
On the rear of the main unit:
≥ Connect only after all other connections are completed.
A To an AC outlet
B AC power supply cord (supplied)
≥This system consumes a small amount of AC power (> p. 30) even when it is turned off. In the interest
of power conservation, if you will not be using this system for a long time, unplug it from the AC outlet.
AC power supply cord connection
TV remote control
signal sensor
Adhesive tape (supplied)
SC-HTB580P_RQT9922-Y.book 12 ページ ２０１３年１２月１９日 木曜日 午前１１時０分
To Next Page
