Panasonic SC-HTB580 User Manual

Before use
RQT9922
7
1 HDMI AV IN (BD/DVD) terminal (> p. 10)
2 HDMI AV OUT (TV (ARC)) terminal (ARC
compatible) (> p. 9, 10)
3 OPTICAL DIGITAL AUDIO IN (TV) terminal
(> p. 10)
4 Ir SYSTEM terminal (> p. 11, 12)
5 AC IN terminal (> p. 12)
6 Active subwoofer on/off button (> p. 19)
§ 1For service use only
§ 2 The I/D SET button is only used when the main unit is not paired with the active subwoofer. (> p. 28)
This system (Rear)
6
2
1
3
4
1
5
2
5
Main unit
Active subwoofer
