24
RQT9825
Specifications
≥ Specifications are subject to change without notice.
≥ Weight and dimensions are approximate.
≥
Total harmonic distortion is measured by a digital spectrum analyzer.
AMPLIFIER SECTION
RMS output power: Dolby Digital Mode
Front ch
30 W per channel (6 ≠), 1 kHz, 10 % THD
Subwoofer ch
30 W per channel (6 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power
90 W
TERMINAL SECTION
Digital audio input (TV)
Optical digital input Optical terminal
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio Format
LPCM, Dolby Digital, DTS Digital Surround
Analog audio input
Audio input Pin jack
USB Port For service use only.
SPEAKER SECTION
Front speakers (Built-in)
Type
2 way, 2 speaker system (Bass Reflex)
Woofer
5.7 cm Cone type
Tweeter
2.5 cm Semi-dome type
Subwoofer (Built-in)
Type
1 way, 1 speaker system (Bass Reflex)
Woofer
8 cm Cone type
GENERAL
Power consumption
20 W
Power consumption in standby mode
Approx. 0.4 W
Power supply AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
950 mmk66 mmk105 mm
Mass
Approx. 3.2 kg
For wall mounting
Dimensions (WkHkD)
950 mmk105 mmk66 mm
Mass
Approx. 3.2 kg
Operating temperature range
0
o
C to i40
o
C
Operating humidity range
20 % to 80 % RH (no condensation)
SC-HTB65EB_RQT9825-B.book 24 ページ ２０１３年２月２１日 木曜日 午前１０時６分
