Gettingstarted
Step 1 Selecting the placement method
≥Choose a placement method that suits you best.
The main unit
When attaching the main unit to a wall
When placing the main unit in a rack or on a table
Angle 1: 0
o
tilt
≥Speaker angle indicator lights green.
[HTB70]
[A]
Raised by using the basic stands
Page 10
[HTB70]
Angle 2: Tilted at 30
o
≥Speaker angle indicator lights amber.
[B]
Tilted by using 30
o
stands
Page 10
[HTB70]
Angle 3: Tilted at 80
o
≥Speaker angle indicator lights red.
[C]
Tilted by using 80
o
stands
Page 10
[HTB70] Angle 3:
[HTB65]
Angle 2:
Tilted at 90
o
≥Speaker angle indicator lights red.
Page 12
