15
RQT9860
Specifications
Amplifier section
RMS output power: Dolby Digital mode
Front Ch 30 W per channel (6 Ω), 1 kHz, 10% THD
Subwoofer Ch
60 W per channel (3 Ω), 100 Hz, 10% THD
Total RMS Dolby Digital mode power 120 W
FTC output power: Dolby Digital mode
Front Ch
16 W per channel (6 Ω), 170 Hz to 20 kHz, 1% THD
Subwoofer Ch
28 W per channel (3 Ω), 45 Hz to 170 Hz, 1% THD
Total FTC Dolby Digital mode power 60 W
Terminals section
HDAVI Control
This unit supports “HDAVI Control 5” function
HDMI AV input
Input connector Type A (19 pin)
HDMI AV output
Output connector Type A (19 pin)
Digital audio input
Optical digital input Optical terminal
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio format
Dolby Digital, DTS Digital Surround, LPCM
Analog audio input
Audio input Pin jack (1 system)
USB port For service use only
Bluetooth
®
section
Bluetooth
®
system specification Version 3.0
Wireless equipment classification Class 2
Supported profiles A2DP
Operating frequency 2402 MHz to 2480 MHz
Operation distance 10 m (33 ft) line of sight
Speaker section
Front speaker (built-in)
Type 1 way, 1 speaker system (bass reflex)
Speaker unit(s)
Full range
3.8 cm x 9 cm (1½″ x 3 ″) cone type x 2
Subwoofer (built-in)
Type 1 way, 2 speaker system (bass reflex)
Speaker unit(s)
Woofer 8 cm (3 ″) cone type x 2
General
Power supply AC 120 V, 60 Hz
Power consumption 27 W
Dimensions (W x H x D) 460 mm x 60 mm x 280 mm
(18⅛″ x 2⅜″ x 11 ″)
Mass (Weight) 3.2 kg (7.1 lbs)
Maximum loading weight 30 kg (66 lbs)
Operating temperature range 0°C to +40°C
(+32°F to +104°F)
Operating humidity range
20% to 80% RH (no condensation)
Note:
• Specifications are subject to change without notice.
Mass (weight) and dimensions are approximate.
• Total harmonic distortion is measured by the digital
spectrum analyzer.
Power consumption in standby mode
(With “BLUETOOTH STANDBY” set to “OFF”)
0.2 W (approximate)
