Specifi cations
AMPLIFIER SECTION
RMS OUTPUT POWER both channel driven
10% total harmonic distortion
For United Kingdom and Continental Europe
1
kHz 50
W per channel (6
Ω)
For Australia and N.Z.
1
kHz
(Low channel)
SC-PM1945
W per channel (6
Ω)
8
kHz
(High channel) SC-PM1945
W per channel (6
Ω)
Total Bi-Amp power SC-PM190
W per channel
Input Impedance
Music port 250 mV 12kΩ
Output Impedance
Headphone 16
Ω to 32
Ω
Phone jack
Terminal Stereo, 3.5 mm
Music port input jack
Terminal Stereo, 3.5 mm
FM TUNER SECTION
Frequency range
87.50
MHz to 108.00
MHz (50
kHz steps)
Sensitivity 0.3
µV (IHF)
S/N 26
dB 0.2
µV
Antenna terminals 75
Ω (unbalanced)
Preset station FM 15 stations
AM 15 stations
AM TUNER SECTION
Frequency range 522 kHz to 1629
kHz (9
kHz steps)
520 kHz to 1630
kHz (10
kHz steps)
Sensitivity
For United Kingdom and Continental Europe
S/N 20
dB (at 999
kHz) 900
µV/m
For Australia and N.Z.
S/N 20
dB (at 1000
kHz) 900
µV/m
CASSETTE DECK SECTION
Track system 4-track, 2-channel
Heads
Record/playback Solid permalloy head
Erasure Double gap ferrite head
Motor DC servo motor
Recording system AC bias 100
kHz
Erase system AC erase 100
kHz
Tape speed 4.8
cm/s
Overall frequency response (+3, –6
dB at DECK OUT)
NORMAL 35
Hz to 14
kHz
S/N RATIO 54
dB (A weighted)
Wow and fl utter 0.08 % (WRMS)
Fast-forward and rewind time
Approx. 120 seconds with C-60 cassette tape
CD SECTION
Disc played [8 cm or 12 cm]
(1) CD-Audio (CD-DA)
(2) CD-R/RW (CD-DA, MP3 formatted disc)
(3) MP3
Sampling frequency
CD 44.1
kHz
MP3 32
kHz, 44.1
kHz, 48
kHz
Bit rate
MP3 32
kbps to 384
kbps
Decoding 16/20/24 bit linear
Pick up
Wavelength 785 nm
Beam source Semiconductor laser
Laser power CLASS 1
(For Norge)
Bølgelengde 785 nm
Laserstyrke Ingen farlig stråling sendes ut
Audio output (Disc)
Number of channels 2-Channel
Frequency response 20
Hz to 20
kHz
(+1dB, -2
dB)
Wow and fl utter Below measurable limit
Digital fi lter 8
fs
D/A converter MASH (1 bit DAC)
SPEAKER SECTION
Type 2 way, 2 speaker system
Speaker(s)
Woofer 10 cm cone type (6
Ω)
Tweeter 6
cm cone type (6
Ω)
Impedance 6
Ω
Input power (IEC)
For United Kingdom and Continental Europe
50
W (Max)
For Australia and N.Z.
HIGH 90
W (Max)
LOW 90
W (Max)
Output sound pressure 80
dB/W (1.0 m)
Crossover frequency
For United Kingdom and Continental Europe
3.5 kHz
For Australia and N.Z.
2.2 kHz
Frequency range
For United Kingdom and Continental Europe
55
Hz to 32
kHz (-16
dB)
78
Hz to 28
kHz (-10
dB)
For Australia and N.Z.
45
Hz to 35
kHz (-16
dB)
50
Hz to 31
kHz (-10
dB)
Dimensions (W x H x D) 144
mm x 249
mm x 200
mm
Mass 1.9 kg
GENERAL
Power supply
For Continental Europe
AC 230V, 50
Hz
For United Kingdom, Australia and N.Z.
AC 230 to 240
V, 50
Hz
Power consumption
For United Kingdom and Continental Europe
125
W
For Australia and N.Z.
156
W
Dimensions (W x H x D) 175
mm x 249
mm x 355
mm
Mass
For United Kingdom and Continental Europe
5.4
kg
For Australia and N.Z.
5.5
kg
Operating temperature range +5°C to +35°C
Operating humidity range
5% to 90% RH (no condensation)
Power consumption in standby mode
For United Kingdom and Continental Europe 0.6
W
For Australia and N.Z.
0.7
W
Note
1. Specifi cations are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
3.
For Australia and N.Z.
The labels “HIGH” and “LOW” on the
rear or the speakers refer to High frequency and Low frequency.
