Specifications
Specifications
RMS Output Power: Dolby Digital Mode
Front Ch 125 W per channel (3 ≠), 1 kHz, 10 % THD
Surround Ch 125 W per channel (3 ≠), 1 kHz, 10 % THD
Center Ch 250 W per channel (6 ≠), 1 kHz, 10 % THD
Subwoofer Ch 250 W per channel (6 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power 1000 W
FTC Output Power: Dolby Digital Mode
Front Ch 63 W per channel (3 ≠), 120 Hz–20 kHz, 1 % THD
Surround Ch 34
W per channel (3
≠
), 120 Hz–20 kHz, 1 % THD
Center Ch
113 W per channel (6
≠
), 120 Hz–20 kHz, 1 % THD
Subwoofer Ch 121 W per channel (6
≠
), 45 Hz–120 Hz,
1% THD
Total FTC Dolby Digital mode power 428 W
Preset Memory FM 30 stations
AM/MW 30 stations
Frequency Modulation (FM)
Frequency range 87.9–107.9 MHz (200-kHz step)
87.5–108.0 MHz (100-kHz step)
Sensitivity 2.5 µV (IHF)
S/N 26 dB 2.2 µV
Antenna terminals 75 ≠ (unbalanced)
Amplitude Modulation (AM/MW)
Frequency range 520–1710 kHz (10-kHz step)
AM Sensitivity S/N 20 dB at 1000 kHz 560 µV/m
Phone jack
Terminal Stereo, 3.5 mm (
1
/
8
z
) jack
Music Port (Front)
Sensitivity 100 mV, 1.2
k
≠
Terminal (Input) Stereo, 3.5 mm (
1
/
8
z
) jack
Discs played [8 cm (3z) or 12 cm (5z)]
(1) DVD (DVD-Video)
(2) DVD-RAM (DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(3) DVD-R (DVD-Video, DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(4) DVD-R DL (DVD-Video, DVD-VR)
(5) DVD-RW (DVD-Video, DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(6) iR/iRW (Video)
(7) iR DL (Video)
(8) CD, CD-R/RW [CD-DA, Video CD, SVCD
§1
, MP3
§2, 5
, WMA
§3, 5
,
JPEG
§4, 5
, HighMAT Level 2 (Audio and Image)]
§1
Conforming to IEC62107
§2
MPEG-1 Layer 3, MPEG-2 Layer 3
§3
Windows Media Audio Ver.9.0 L3
Not compatible with Multiple Bit Rate (MBR)
§4
Exif Ver 2.1 JPEG Baseline files
Picture resolution: between 160k120 and 6144k4096 pixels (Sub
sampling is 4:0:0, 4:2:0, 4:2:2 or 4:4:4). Extremely long and narrow
pictures may not be displayed.
§5
The total combined maximum number of recognizable audio and
picture contents and groups: 4000 audio and picture contents and
400 groups.
Pick up
Wavelength (DVD/CD) 662/785 nm
Laser power (DVD/CD) [U.S.A.[ CLASS II /CLASS I
[Canada[ CLASS 1/CLASS 1M
Audio output (Disc)
Number of channels 5.1ch (FL, FR, C, SL, SR, SW)
Video system NTSC
Composite video output
Output level 1 Vp-p (75 ≠)
Terminal Pin jack (1 system)
Component video output (480p/480i)
Y output level 1 Vp-p (75 ≠)
P
B output level 0.7 Vp-p (75 ≠)
P
R output level 0.7 Vp-p (75 ≠)
Terminal Pin jack (Y: green, P
B: blue, PR: red) (1 system)
HDMI AV output
Terminal Type A connector (19-pin), CEC Ver.1.3a
[Front\speakers\SB-HF650]
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 3 ≠
Full range 6.5 cm (2
1
/2z) Cone type
Input power (IEC) 125 W
§6
(Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 95 Hz–25 kHz (j16 dB)
120 Hz–22 kHz (j10 dB)
Dimensions (WtHtD) 92 mmk142 mmk95 mm
(3
5
/8zk5
19
/32zk3
3
/4z)
Mass 0.6 kg (1.32 lbs)
[Surround\speakers\SB-HS650]
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 3 ≠
Full range 6.5 cm (2
1
/2z) Cone type
Input power (IEC) 125 W
§6
(Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 95 Hz–25 kHz (j16 dB)
120 Hz–22 kHz (j10 dB)
Dimensions (WtHtD) 92 mmk142 mmk95 mm
(3
5
/8zk5
19
/32zk3
3
/4z)
Mass 0.6 kg (1.32 lbs)
[Center\speaker\SB-HC750]
Type 1 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 6 ≠
1. Full range 6.5 cm (2
1
/2z) Cone type
2. Full range 6.5 cm (2
1
/2z) Cone type
Input power (IEC) 250 W
§6
(Max)
Output sound pressure 82 dB/W (1.0 m)
Frequency range 80 Hz–25 kHz (j16 dB)
96 Hz–22 kHz (j10 dB)
Dimensions (WtHtD) 270 mmk94 mmk95 mm
(10
5
/8zk3
11
/16zk3
3
/4z)
Mass 1.3 kg (2.9 lbs)
[Subwoofer\SB-HW750]
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 6 ≠
Woofer 16 cm (6
1
/2z) Cone type
Input power (IEC) 250 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Frequency range 29 Hz–220 Hz (j16 dB)
36 Hz–180 Hz (j10 dB)
Dimensions (WtHtD) 178 mmk425 mmk257 mm
(7zk16
23
/32zk10
1
/8z)
Mass 4kg (8.8 lbs)
Power supply AC 120 V, 60 Hz
Power consumption Main unit 135 W
Dimensions (WtHtD) 430 mmk70 mmk424 mm
(1
6
15
/
16
zk
2
15
/
16
zk
16
11
/
16
z
)
Mass Main unit 5 kg (11.02 Ibs)
Operating temperature range r5 oC to r35 oC (r41 oF to r95 oF)
Operating humidity range 5 % to 90 % RH (no condensation)
§6
Rating with low-cut filter equipped amplifier
[Note]
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by a digital spectrum analyzer.
AMPLIFIER SECTION
FM/AM TUNER, TERMINALS SECTION
DISC SECTION
VIDEO SECTION
SPEAKER SECTION
GENERAL
Power consumption in standby mode approx. 0.5 W
