7
TQBJ2189
T DJ function direct buttons
Press [DJ] to switch on the DJ function.
Press [DJ1] to [DJ6] to select the desired function.
To cancel, press the selected [DJ1] to [DJ6] again.
U Microphone jack
V :USB A
USB port ( )
Play MP3 tracks.
W :USB B
USB port ( )
Play MP3 tracks.
Record sound or music tracks.
X Remote control sensor
Point the remote control at the remote control
sensor, away from obstacles and within the
operation range.
Distance: Within approximately 7 m
Angle: Approximately 20° up and down, 30° left
and right
Y Display panel
Z Disc tray
SELECT
VOL
DJ6
DJ5
DJ4
DJ3
DJ2
DJ1
SOUND
JUKEBOX
KARAOKE
ALBUM/
TRACK
ILLUMINATION
Top panel
SC-TMAX40.50PU_TQBJ2189 En.fm Page 7 Wednesday, June 12, 2019 3:29 PM
offset printing

Panasonic SC-TMAX40 Specifications

General

Tweeter	Yes
Woofer diameter	100 mm
Tweeter diameter	60 mm
Audio output channels	2.1 channels
Subwoofer driver diameter	200 mm
AC adapter input voltage	220 - 240 V
Preset stations quantity	30
Impedance	6 Ω
RMS rated power	1200 W
Peak Music Power Output (PMPO)	13200 W
Total Harmonic Distortion (THD)	30 %
Wi-Fi	No
USB port	-
Bluetooth version	5.0
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wired
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	MP3
Mobile operating systems supported	Android
AC adapter frequency	50 Hz
Power consumption (standby)	0.6 W
Power consumption (typical)	196 W

Weight and Dimensions

Depth	326 mm
Width	305 mm
Height	804 mm
Weight	17500 g
Package depth	380 mm
Package width	880 mm
Package height	420 mm
Package weight	20000 g
