Panasonic SC-TMAX40 User Manual

Confidential
Until:
24 Jun 2019
9
TQBJ2189
Media playback
The following marks indicate the availability of the feature.
Basic playback
CD ::USB BLUETOOTH
Note:
Depending on the Bluetooth
®
device, some operations may not
work.
Viewing available information
:CD ::USB BLUETOOTH
You can view the available information, such as MP3
album and track number, on the display panel.
Press [DISPLAY] repeatedly.
Example: MP3 album and track number display.
Note:
• Maximum characters that can be shown: Approximately 32
• This system supports ver. 1.0, 1.1 and 2.3 ID3 tags.
• Text data that the system does not support can show
differently.
Play menu
:CD ::USB
1 :CD :
Press [PLAY MENU].
:USB
Press [PLAY MENU] repeatedly to select
“PLAYMODE”.
2 Press [R, T] to select the setting and then press
[OK].
Note:
• During random playback, you cannot skip to tracks which
have been played.
• The setting is canceled when you open the disc tray or
disconnect the USB device.
CD :
:USB :
BLUETOOTH :
CD-R/RW in CD-DA format or with MP3
files.
USB device with MP3 files.
Bluetooth
®
device.
Play Press [4/9].
Stop Press [8].
USB
The position is memorized.
“RESUME” is shown.
Press again to stop fully.
Pause Press [4/9].
Press again to continue playback.
Skip Press [2/3] or [5/6] to skip track.
:CD ::USB
Press [R, T] to skip MP3 album.
Search Press and hold [2/3] or [5/6].
Album
number
Track
number
OFF PLAYMODE Cancel the setting.
1-TRACK Play one selected track.
Press [2/3] or [5/6] to
select the track.
1-ALBUM Play one selected MP3 album.
Press [R, T] to select the MP3
album.
RANDOM Play all tracks randomly.
1-ALBUM
RANDOM
Play all tracks in one selected MP3
album randomly.
Press [R, T] to select the MP3
album.
ALL REPEAT Repeat all tracks.
1-TRACK REPEAT Repeat 1-TRACK.
1-ALBUM REPEAT Repeat 1-ALBUM.
RANDOM REPEAT Repeat random playback.
1-ALBUM
RANDOM REPEAT
Repeat 1-ALBUM RANDOM.
SC-TMAX40.50PU_TQBJ2189 En.fm Page 9 Wednesday, June 12, 2019 3:29 PM
offset printing

Panasonic SC-TMAX40 Specifications

General

Tweeter	Yes
Woofer diameter	100 mm
Tweeter diameter	60 mm
Audio output channels	2.1 channels
Subwoofer driver diameter	200 mm
AC adapter input voltage	220 - 240 V
Preset stations quantity	30
Impedance	6 Ω
RMS rated power	1200 W
Peak Music Power Output (PMPO)	13200 W
Total Harmonic Distortion (THD)	30 %
Wi-Fi	No
USB port	-
Bluetooth version	5.0
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wired
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	MP3
Mobile operating systems supported	Android
AC adapter frequency	50 Hz
Power consumption (standby)	0.6 W
Power consumption (typical)	196 W

Weight and Dimensions

Depth	326 mm
Width	305 mm
Height	804 mm
Weight	17500 g
Package depth	380 mm
Package width	880 mm
Package height	420 mm
Package weight	20000 g
