12
No. Part No. Part Name & Description SR-TEG10 SR-TEG18 Remark
A XTB4+10GFJ TAPPING SCREW 2 2 For Handle
B XYN4+C10FNS SEMS SCREW 1 1 For Cast heater
C XTN4+6FFJ TAPPING SCREW 1 1 For Thermal fuse ass’y
C XTN4+6FFJ TAPPING SCREW 2 2 For Frame ass’y
D XYN4+C7FNS SEMS SCREW 2 2 For Wiring
E XWA4BPW SPRING WASHER 1 1 Together with XTN4+8FFJ
F XTN4+8FFJ TAPPING SCREW 1 1 For Body earth lead wire
G ASR118-972-W TAPPING SCREW 1 1 For Bottom frame
H XTN4+16AVW TAPPING SCREW 1 1 For Hinge cover
9.3 Packing Specification
No. Part No. Part Name & Description SR-TEG10 SR-TEG18 Remark
1 ARZ19H9201 OPERATING INSTRUCTION 1 1
2 ARZ80T921-0U UPPER PAD ASS’Y 1 -
2 ARZ80T920-0U UPPER PAD ASS’Y - 1
3 ASR762T929-K POLYETHYLENE SHEET 1 1
4 ASR758T344B RUST PROOF PAPER 1 1
5 ASR761H915-K CORD PROTECTOR 1 1
6 ARZ11T921-0U LOWER PAD ASS’Y 1 -
6 ARZ11T920-0U LOWER PAD ASS’Y - 1
7 ARZ01V921-HO PACKING CASE 1 -
7 ARZ01V920-HO PACKING CASE - 1
8 ARZ80S9211SP POS LABEL 1 - For SR-TEG10-SP
8 ARZ80S9211CS POS LABEL 1 - For SR-TEG10-CS
8 ARZ80S9201SP POS LABEL - 1 For SR-TEG18-SP
8 ARZ80S9200CS POS LABEL - 1 For SR-TEG18-CS
9.2 Small standardized metal parts
No. Part No. Part Name & Description SR-TEG10 SR-TEG18 Remark
31 ARY30S921-SP NAME PLATE 1 - SOFT PINK
31 ARY30S921-CS NAME PLATE 1 - CRYTAL SILVER
31 ARY30S92O-SP NAME PLATE - 1 SOFT PINK
31 ARY30S920-CS NAME PLATE - 1 CRYTAL SILVER
32 ASR792-454BK MEASURING CUP 1 1
33 ASR79WT281AK SCOOP 1 1
34 ARK53H617-W9 STEAM BASKET 1 -
34 ARK53H616-W9 STEAM BASKET - 1
9.1 Replacement parts
SR-TEG18 , SR-TEG10
