Section 7 – Fiber Options
36
AJA FIDO TR
Mounts to AG-CA-300
Bracket Not Shown
AC Adaptor
12VDC Cable
To Camera D-Tap
Single Mode Duplex Fiber Up To 6.2 Miles
AG-BS300
Base Station
AG-EC4
AG-CA300
Mounts to Camera Back
SDI I/O
SDI I/O
The Studio System Works With the Following Cameras:
AG-HPX300, AG-HPX370, AG-HPX500, AJ-HDX900, AJ-HPX2000, AJ-HPX2700, AJ-HPX3000, AJ-HPX3100, AJ-HPX3700
AC IN
12 VDC IN
VIA Gold Mount
(adaptor not shown)
ROP, GEN LOCK and SDI Connections
Panasonic Solutions Company
