Panasonic SU-HTB550PH

11
3.3. Different Points
3.3.1. Main Unit (SU-HTB550)
Ref. No. Parts No. Parts name & Description Remarks
SU-HTB550PCK SU-HTB550PHK
11 RGR0423B-B2 RGR0423B-G REAR PANEL
12 RYP1694-K RYP1694D-K FRONT PANEL ASSY
13 RGU2775-K RGU2775-K1 VOLUME BUTTON
C2101 F1G1H101A565 _ 100pF 50V
C2102 F1G1H101A565 _ 100pF 50V
C2105 F1G0J105A031 _ 1uF 6.3V
C2106 F1G0J105A031 _ 1uF 6.3V
C2107 F1J1A106A043 _ 10uF 10V
C2108 F1J1A106A043 _ 10uF 10V
C2109 F1J1A106A043 _ 10uF 10V
C2110 F1J1A106A043 _ 10uF 10V
C2111 F1G1H101A565 _ 100pF 50V
C2112 F1G1H101A565 _ 100pF 50V
C2113 F1G1A1040006 _ 0.1uF 10V
C2114 F1J1A106A043 _ 10uF 10V
C2115 F1G1A1040006 _ 0.1uF 10V
C2116 F1J1A106A043 _ 10uF 10V
C2117 F1G1A1040006 _ 0.1uF 10V
C2118 F1J1A106A043 _ 10uF 10V
C2119 EEEHB0J101UR _ 100uF 6.3V
C2120 F1G1A1040006 _ 0.1uF 10V
C5700 F1BAF1020020 F1BAF471A013 470pF
C5705 F1BAF1020020 F1BAF471A013 470pF
C5712 F2B2D1810007 F2A2G1810002 180uF 400V
CN2111 K1MY12AA0021 _ 12P CONNECTOR
D6008 B3AEA0000166 _ DIODE
DZ5701 ERZVA5Z471 ERZV10V511CS ZNR
IC2101 C0ABBA000159 _ IC
IC2102 C0FBAK000026 _ IC
IC2103 C0JBAR000396 _ IC
IC5701 C0DABYY00035 C0DAAYY00064 IC
K100 D0GBR00JA008 _ 0 1/10W
K101 - D0GBR00JA008 0 1/10W
K111 D0GAR00J0008 _ 0 1/16W
K113 _ D0GAR00J0008 0 1/16W
K211 D0GAR00J0008 _ 0 1/16W
K213 _ D0GAR00J0008 0 1/16W
K5722 ERJ3GEY0R00V _ 0 1/10W
K5724 _ ERJ3GEY0R00V 0 1/10W
L2805 G1C330MA0291 G1C330M00028 INDUCTOR
L5702 _ ELF19H820E LINE FILTER
LB2101 J0JYB0000013 _ INDUCTOR
LB2102 J0JYB0000013 _ INDUCTOR
LB2103 J0JBC0000014 _ INDUCTOR
LB2104 J0JBC0000014 _ INDUCTOR
LB2105 J0JBC0000014 _ INDUCTOR
LB2106 J0JHC0000078 _ INDUCTOR
P5701 K2AB2B000007 K2AA2B000011 AC INLET
PCB1 REP4735E REP4735D MAIN P.C.B. (RTL)
PCB3 REP4792AA REP4792BA PANEL P.C.B. (RTL)
PCB4 REP4792AB REP4792BB BUTTON P.C.B. (RTL)
PCB5 REP4792AC REP4792BC POWER BUTTON P.C.B. (RTL)
PCB6 REP4792AD REP4792BD WIRELESS ADAPTER P.C.B. (RTL)
PCB7 REP4737LA REP4737NA SMPS P.C.B. (RTL)
PCB8 REP4777A REP4813A DIGITAL TRANSMITTER MODULE
P. C. B .
PCB9 REP4805A - BLUETOOTH MODULE P.C.B.
R2101 ERJ2GEJ104X _ 100K 1/16W
R2103 ERJ2GEJ223X _ 22K 1/16W
R2104 ERJ2GEJ223X _ 22K 1/16W
R2105 ERJ2GEJ223X _ 22K 1/16W
