60
IC4700
INPUT OUTPUT
Pin31 Pin27 Pin28 Pin29 Pin30 Pin4
L L L L L
0.1V
H L L L L
3.3V
X
H L L L 2.55V
X
X H L L 1.95V
X
X X H L 1.35V
X
X X X H 0.75V
IC4700 Block Diagram
