9 Block Diagram
9.1. Main Block Diagram
Debug
UART
RST
STB5V
24M
1.8/3.3V
RST
PANEL
SP
SP
15V
I2S
HDMI 1
TUNER
HDMI 2 (w/ ARC)
MT5561
DDR2 1G
VIDEO/COMPONENT (automatic detection )
AUDIO
Silicon Lab
Low IF
SUB3.3V
SPI
64/128Mb
Sub3.3V
EEP_WP
EEPROM
64kbit
SLV[A4]
On-board
USB Slot
High-side
switch
USB(side) JK8601
Audio AMP
I2S AMP
RMT/KEY
LED
32/40/43/
49/55”
㨪 10W x 2
*&(*&
LVDS
HD : (DATA 4pairs / CLK 1pair)
single8bit
FHD: (DATA 4pairs / CLK 1pair)
dual8bit
Op Amp
IIC
Australia CAN(LG)
Singapore On board (Si2157 )
YAMAHA
VIDEO
AUDIO
AV2(side)
JK3002(Prep)
Monitor out JK3000(Prep.)
AV1 JK3100
(HDMI analog audio in)
HDMI1 JK4701
HDMI2 JK4702
CEC
Opt. D3051
Demod.
T2/ISDB/DTMB
TS
Taiwan
Tunerless
Sub woofer
15V
Audio AMP
I2S AMP
YAMAHA
For E460 series only
