Panasonic TH-32F400A - 10 Wiring Connection Diagram; Wire Dressing

TH-32F400A TH-32F400Z
26
10 Wiring Connection Diagram
10.1. Wire Dressing 1
Arrange the wire dressing as below spec.
No Description Qty UOM Remarks
01 PET TAPE 0.36 MT 0.06 × (6 PCS)
02 PET TAPE 0.11 MT 0.11 × (1 PCS)
03 LVDS CABLE 1 PC
