Panasonic TH-37PV80P

133
D415 B0JAME000099 DIODE 1
D416 B0HAMP000067 DIODE 1
D417 B0HAPR000012 DIODE 1
D418 B0BC8R100013 ZENER DIODE 1
D419,20 B0HAPR000013 DIODE 2
D423 MA188 DIODE 1
D425 MA188 DIODE 1
D429 B0EAKT000048 DIODE 1
D431 B0JCDD000002 DIODE 1
D433 B0BC01400033 ZENER DIODE 1
D435 B0EAKT000048 DIODE 1
D436 MA165TA5 DIODE 1
D438 B0BC02000014 ZENER DIODE 1
D439 B0EAKT000048 DIODE 1
D441 B0HAMM000122 DIODE 1
D444 B0HAMM000122 DIODE 1
D445 MTZJ10B ZENER DIODE 1
D450 B0ACDJ000010 DIODE 1
D501 B0HAPR000012 DIODE 1
D502 B0BC8R100013 ZENER DIODE 1
D503,04 MA165TA5 DIODE 2
D506 B0ACDJ000010 DIODE 1
D509 B0JANG000018 DIODE 1
D511 B0JAML000011 DIODE 1
D512,13 B0ACDJ000010 DIODE 2
D516-18 B0BA03300004 ZENER DIODE 3
D520 B0ACDJ000010 DIODE 1
D521 B0JAME000099 DIODE 1
D522,23 B0JCDD000002 DIODE 2
D530 B0ACDJ000010 DIODE 1
D531 B0HBSN000013 DIODE 1
D535 MA188 DIODE 1
D536 MA3DD82 DIODE 1
D538 B0BC5R100039 ZENER DIODE 1
D539,40 B0HARR000019 DIODE 2
D543 B0BC01400033 ZENER DIODE 1
D544,45 B0BA02100001 ZENER DIODE 2
D546 B0BA02800001 ZENER DIODE 1
D549 B0BC02500008 ZENER DIODE 1
D569,70 B0BA05100010 ZENER DIODE 2
D579 MA165TA5 DIODE 1
D582 MAZ705600F ZENER DIODE 1
D584 MAZ706200F ZENER DIODE 1
D586 B0HAMP000067 DIODE 1
D598 B0BC5R100039 ZENER DIODE 1
D599 B0JCND000009 DIODE 1
D600 B0BC7R400023 ZENER DIODE 1
D601 B0BC5R100039 ZENER DIODE 1
D602 B0BC8R100013 ZENER DIODE 1
D603 B0BA01900005 ZENER DIODE 1
D701 B0BC5R100039 ZENER DIODE 1
F401,02 K5E802BZ0002 FUSE 2
F403 K5G631B00007 FUSE 1
IC401 CNC1S171R IC 1
IC403 CNC1S171R IC 1
IC406 C0DBZZZ00082 IC 1
IC408 B3PBA0000459 IC 1
IC409 MIP3E30MPSCF IC 1
IC411 C0DBZMC00006 IC 1
IC501 C2ABDB000118 IC 1
IC502 C0EBH0000210 IC 1
IC504 C0DBZMC00006 IC 1
IC505 B3PBA0000459 IC 1
IC506 C0DBZMC00006 IC 1
IC507 B3PBA0000459 IC 1
IC508 C0DBZMC00006 IC 1
IC509 C0BBAA000093 IC 1
IC510 C0DBAZG00034 IC 1
IC511-13 C0DBZMC00006 IC 3
IC520 LSSK0087 IC 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
L403 EXCELSA35 BEAD CHOKE 1
L404,05 G0B123K00004 CHOKE COIL 2
L406 J0JCC0000004 CHIP INDUCTOR 1
L410 G0B353D00002 CHOKE COIL 1
L511 G0C470MA0056 PEAKING COIL 1
L512 TALL08N4R7MA INDUCTION COIL 1
L514 G0A100GA0013 CHOKE COIL 1
L515 J0JKB0000037 FLAT CORE 1
L518 J0JCC0000004 CHIP INDUCTOR 1
P2 K1KA02A00676 2P CONNECTOR 1
P6 K1KA12AA0191 12P CONNECTOR 1
P7 K1KA11AA0191 11P CONNECTOR 1
P9 K1KA03A00608 3P CONNECTOR 1
P11 K1KA02A00676 2P CONNECTOR 1
P12 K1KA08A00514 8P CONNECTOR 1
P25 K1KA13AA0194 13P CONNECTOR 1
PMM1 LSGQ0234 CLAMPER 1
PMM2,M3 LSGQ0235 CLAMPER 2
PMM5 LSGQ0235 CLAMPER 1
PMM6 TMME260 CLAMPER 1
PR401 K5Y502BA0001 FUSE 1
PR402 ERBSE0R50U FUSE 1
PR501 ERBSE0R50U FUSE 1
PR505 ERBSE5R00U FUSE 1
PR509 ERBSE0R50U FUSE 1
PR601 K5G312B00012 FUSE 1
Q401 B1CHND000004 FET 1
Q402 B1CBGD000001 FET 1
Q404 B1BCCF000022 TRANSISTOR 1
Q406 B1DEHQ000014 FET 1
Q407 B1HFCFA00021 TRANSISTOR 1
Q408,09 B1CHND000004 FET 2
Q411 B1HFCFA00021 TRANSISTOR 1
Q412,13 B1DAGQ000013 FET 2
Q420 2SD1819ARL TRANSISTOR 1
Q501,02 2SD1820A0L TRANSISTOR 2
Q507 B1DAGQ000013 FET 1
Q508 2SD1819ARL TRANSISTOR 1
Q509 B1HDCEA00001 TRANSISTOR 1
Q510 B1DFDD000019 FET 1
Q517 B1HBCFA00033 TRANSISTOR 1
Q520 B1HBCFA00033 TRANSISTOR 1
Q521 B1CBGD000001 FET 1
Q527 B1CERM000012 FET 1
Q530 B1ADCF000111 TRANSISTOR 1
Q537 B1CFQD000001 FET 1
Q538 2SD1819ARL TRANSISTOR 1
Q540 B1DFDD000019 FET 1
Q541 B1CBGD000001 FET 1
Q553 2SD1819ARL TRANSISTOR 1
Q554 B1CHND000004 FET 1
Q555 B1CFRD000018 FET 1
Q563 2SD1819ARL TRANSISTOR 1
Q564,65 B1ADCF000111 TRANSISTOR 2
Q566 2SD1819ARL TRANSISTOR 1
Q569 B1CBGD000001 FET 1
R401 ERJ6GEYG103 M 10KOHM,J,1/10W 1
R402 ERJ6GEYG821 M 820 OHM,J,1/
10W
1
R403 D0GB105JA057 M 1M OHM F 1/16W 1
R404 ERJ6GEYG153 M 15KOHM,J,1/10W 1
R405 D0B1825JA033 M1.22MOHM,J,0.05
W
1
R406 ERX12SJ4R7 M 4.7 OHM, J,1/
2W
1
R407 D1AB2203A023 CHIP RESISTOR 1
Safety Ref. No. Part No. Part Name &
Description
Pcs Remarks
