Temperatuer 32 °F - 104 °F (0 °C - 40 °C)
Humidity 20 % - 80 %
Applicable signals
Color System NTSC, PAL, PAL60, SECAM, Modified NTSC
Scanning format 525 (480) / 60i 60p, 625 (575) / 50i 50p, 750 (720) / 60p 50p, 1125 (1080) / 60i 50i 24p 25p
30p 24sF .... SMPTE274M, 1250 (1080) / 50i
PC signals VGA display
VGA
SVGA, XGA, SXGA, UXGA ..... (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
A
V (EK/S, BK, S, UK) VIDEO IN / OUT (BNC) 1.0 Vp-p (75-ohm or high impedance)
S VIDEO IN (MINI DIN 4PIN) Y: 1 Vp-p (75-ohm), C: 0.286 Vp-p (75-ohm)
A
UDIO IN (RCA PIN JACK ×2) 0.5 Vrms (high impedance)
COMPONENT / RGB (UK) Y / G (BNC) 1.0 Vp-p / composite (75-ohm)
0.7 Vp-p / non-composite (75-ohm)
P
B
/ B (BNC), P
R
/ R (BNC) 0.7 Vp-p (75-ohm)
A
UDIO IN (RCA PIN JACK × 2) 0.5 Vrms (high impedance)
PC (GK/GS/UK) (HIGH-DENSITY D-SUB 15PIN) R, G, B / 0.7 Vp-p (75-ohm)
Component
Y:1.0 Vp-p (75-ohm : include sync)
P
B
/C
B
:±0.7 Vp-p (75-ohm)
P
R
/C
R
:±0.7 Vp-p (75-ohm)
HD, VD / 1.0 - 5.0 Vp-p (high impedance)
A
UDIO IN (M3 JACK) 0.5 Vrms (high impedance)
PC (EK/ES/BK/BS) (HIGH-DENSITY D-SUB 15PIN) R, G, B / 0.7 Vp-p (75-ohm)
HD, VD / 1.0 - 5.0 Vp-p (high impedance)
A
UDIO IN (M3 JACK) 0.5 Vrms (high impedance)
SERIAL EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE
SPEAKERS (6 W) 16 W [8 W + 8 W] (10 % THD)
Accessories Supplied
Remote Control Transmitter EUR7636070R
Batteries 2 × AA Size
Fixing bands (TMME203 or TMME187) × 2
Dimensions ( W × H × D ) 36.2” (920 mm) × 21.7” (550 mm) × 3.5” (89 mm)
(exclusive of protruding portion) (37 inch)
40.2” (1,020 mm) × 24” (610 mm) × 3.5” (89 mm)
(exclusive of protruding portion) (42 inch)
Mass (Weight) (UK)
main unit only approx. 55.1 lbs (37PWD8UK) approx. 65.0 lbs (42PWD8UK)
with speakers approx. 63.9 lbs (37PWD8UK) approx. 73.9 lbs (42PWD8UK)
Mass (Weight) (GK/GS)
main unit only approx. 54.0 lbs (37PWD8GK/GS) approx. 63.9 lbs (42PWD8GK/GS)
with speakers approx. 62.8 lbs (37PWD8GK/GS) approx. 72.8 lbs (42PWD8GK/GS)
Mass (Weight) (EK/S, BK/S)
main unit only approx. 25.0 kg net (37PWD8EK/ES/BK/BS) approx. 29.5 kg net (42PWD8EK/ES/BK/BS)
with speakers approx. 29.0 kg (37PWD8EK/ES/BK/BS) approx. 33.5 kg (42PWD8EK/ES/BK/BS)
Notes:
·
· ·
· Design and specifications are subject to change without notice. Mass and dimensions shown are approximate.
·
· ·
· This equipment complies with the EMC standards listed below. EN55022, EN55024, EN61000-3-2, EN61000-3-3.
