44
Applicable Input Signals
*Mark: Applicable input signal
Signal name
Horizontal
frequency (kHz)
Vertical
frequency (Hz)
RGB IN
(Dot clock (MHz))
PC IN
(Dot clock (MHz))
DVI-D IN
(Dot clock (MHz))
HDMI1
HDMI2
1 640x400@70Hz 31.46 70.07 * (25.17) * (25.17) * (25.17)
2 640x400@85Hz 37.86 85.08 * (31.5) * (31.5) * (31.5)
3 640x480@60Hz 31.43 59.88 * (25.15) * (25.15) * (25.15)
4 640x480@60Hz 31.47 59.94 * (25.18) * (25.18) * (25.18) *
5 640x480@67Hz 35.00 66.67 * (30.24) * (30.24) * (30.24)
6 640x480@72Hz 37.86 72.81 * (31.5) * (31.5) * (31.5)
7 640x480@75Hz 37.50 75.00 * (31.5) * (31.5) * (31.5)
8 640x480@85Hz 43.27 85.01 * (36.0) * (36.0) * (36.0)
9 720x400@70Hz 31.47 70.08 * (28.32) * (28.32) * (28.32)
10 800x600@55Hz 34.50 55.38 * (35.33) * (35.33) * (35.33)
11 800x600@56Hz 35.16 56.25 * (36.0) * (36.0) * (36.0)
12 800x600@60Hz 37.88 60.32 * (40.0) * (40.0) * (40.0) *
13 800x600@60Hz 38.00 60.51 * (40.13) * (40.13) * (40.13)
14 800x600@72Hz 48.08 72.19 * (50.0) * (50.0) * (50.0)
15 800x600@75Hz 46.88 75.00 * (49.5) * (49.5) * (49.5)
16 800x600@85Hz 53.67 85.06 * (56.25) * (56.25) * (56.25)
17 852x480@60Hz 31.47 59.94 * (33.54) * (33.54) * (34.24)
18 1,024x768@50Hz 39.55 50.00 * (51.89) * (51.89) * (51.89)
19 1,024x768@60Hz 48.36 60.00 * (65.0) * (65.0) * (65.0) *
20 1,024x768@60Hz 48.50 60.02 * (64.99) * (64.99) * (65.18)
21 1,024x768@70Hz 56.48 70.07 * (75.0) * (75.0) * (75.0)
22 1,024x768@75Hz 60.24 74.93 * (80.0) * (80.0) * (80.0)
23 1,024x768@75Hz 60.02 75.03 * (78.75) * (78.75) * (78.75)
24 1,024x768@75Hz 61.01 75.70 * (80.05) * (80.05) * (81.0)
25 1,024x768@85Hz 68.68 85.00 * (94.5) * (94.5) * (94.5)
26 1,024x768@120Hz 97.55 119.99 * (115.5) * (115.5)
27 1,066x600@60Hz 37.64 59.94 * (53.0) * (53.0) * (53.0)
28 1,152x864@60Hz 53.70 60.00 * (81.62) * (81.62) * (81.62)
29 1,152x864@75Hz 67.50 75.00 * (108.0) * (108.0) * (108.0)
30 1,152x900@65Hz 61.20 65.20 * (92.0) * (92.0) * (92.0)
31 1,152x900@66Hz 61.85 66.00 * (94.5) * (94.5) * (94.5)
32 1,152x900@75Hz 71.40 75.60 * (105.1) * (105.1) * (105.1)
33 1,280x768@60Hz 47.78 59.87 * (79.50) * (79.50) * (79.50)
34 1,280x800@50Hz 41.20 50.00 * (68.55) * (68.55) * (68.55)
35 1,280x960@60Hz 60.00 60.00 * (108.0) * (108.0) * (108.0)
36 1,280x960@85Hz 85.94 85.00 * (148.5) * (148.5) * (148.5)
37 1,280x1,024@50Hz 52.70 50.00 * (89.38) * (89.38) * (89.38)
38 1,280x1,024@60Hz 63.34 59.98 * (108.18) * (108.18) * (108.18)
39 1,280x1,024@60Hz 63.90 60.00 * (107.35) * (107.35) * (107.35)
40 1,280x1,024@60Hz 63.37 60.01 * (107.5) * (107.5) * (107.5)
41 1,280x1,024@60Hz 63.74 60.02 * (108.1) * (108.1) * (108.1)
42 1,280x1,024@60Hz 63.98 60.02 * (108.0) * (108.0) * (108.0) *
43 1,280x1,024@60Hz 63.79 60.18 * (108.19) * (108.19) * (108.19)
44 1,280x1,024@66Hz 70.66 66.47 * (119.84) * (119.84) * (119.84)
45 1,280x1,024@75Hz 79.98 75.02 * (135.0) * (135.0) * (135.0)
46 1,280x1,024@76Hz 81.13 76.11 * (135.0) * (135.0) * (135.0)
47 1,280x1,024@85Hz 91.15 85.02 * (157.5) * (157.5)
48 1,360x768@60Hz 47.71 60.02 * (85.5) * (85.5) * (85.5)
49 1,366x768@50Hz 39.55 50.00 * (69.92) * (69.92) * (69.92)
50 1,366x768@60Hz 48.36 60.00 * (86.71) * (86.71) * (87.44)
51 1,400x1,050@60Hz 65.12 59.91 * (121.38) * (121.38) * (122.43)
52 1,400x1,050@60Hz 65.32 59.98 * (121.75) * (121.75) * (121.75)
53 1,400x1,050@60Hz 65.35 60.12 * (121.81) * (121.81) * (121.85)
54 1,400x1,050@75Hz 82.28 74.87 * (156.0) * (156.0) * (156.0)
55 1,600x1,200@60Hz 75.00 60.00 * (162.0) * (162.0) * (162.0)
56 1,920x1,080@60Hz 67.50 60.00 * (148.5) * (148.5) * (148.5)
57 1,920x1,200@60Hz 74.04 59.95 * (154.0) * (154.0)
58 Macintosh13" (640x480) 35.00 66.67 * (30.24) * (30.24) * (30.24)
59 MacintoshLC13" (640x480) 34.97 66.60 * (31.33) * (31.33) * (31.33)
60 Macintosh16" (832x624) 49.72 74.55 * (57.28) * (57.28) * (57.28)
61 Macintosh19" (1,024x768) 60.24 75.08 * (80.0) * (80.0) * (80.0)
62 Macintosh21" (1,152x870) 68.68 75.06 * (100.0) * (100.0) * (100.0)
63 Macintosh II (1,280x1,024) 80.00 75.00 * (134.4) * (134.4) * (135.2)
PC signals
