Panasonic TH-84EF1U - Specifications

95
English
Specifications
Model No.
84-inch model
:
TH-84EF1U
75-inch model
:
TH-75EF1U
84-inch model
:
TH-84EF1W
75-inch model
:
TH-75EF1W
Power Consumption
84-inch model
535 W
75-inch model
285 W
Power off condition
0.3 W
Stand-by condition
0.5 W
LCD Display panel
84-inch model
84-inch IPS panel (Edge LED backlight), 16:9 aspect
ratio
75-inch model
75-inch IPS panel ( Edge LED backlight), 16:9 aspect
ratio
Screen size
84-inch model
1 860 mm (W) × 1 046 mm (H) × 2 134 mm (diagonal) /
73.3” (W) × 41.2” (H) × 84.0” (diagonal)
75-inch model
1 649 mm (W) × 927 mm (H) × 1 892 mm (diagonal) /
64.9” (W) × 36.4” (H) × 74.4” (diagonal)
Resolution
1 920 (Horizontal) × 1 080 (Vertical)
Dimensions (W × H × D)
84-inch model
1 910 mm × 1 102 mm × 78 mm / 75.2” × 43.4” × 3.1”
75-inch model
1 681 mm × 959 mm × 77 mm / 66.2” × 37.8” × 3.0”
Mass
84-inch model
approx. 70 / 154 lbs net
75-inch model
approx. 55 / 121 lbs net
Power source
TH-84EF1U, TH-75EF1U:
110‒127V~(110‒127Valternatingcurrent),
50/60Hz
TH-84EF1W, TH-75EF1W:
220‒240V~(220‒240Valternatingcurrent),
50/60Hz
Operating condition
Temperature
0°C‒40°C(32°F‒104°F)
*
1
Humidity
20%‒80%(nocondensation)
Storing condition
Temperature
-20°C‒60°C(-4°F‒140°F)
Humidity
20%‒80%(nocondensation)
Connection terminals
HDMI 1
HDMI 2
TYPE A Connector
*
2
× 2
Audio signal:
Linear PCM (sampling frequencies - 48 kHz,
44.1 kHz, 32 kHz)
DVI-D IN
DVI-D 24 Pin × 1:
Compliance with DVI Revision 1.0
Content Protection:
Compatible with HDCP 1.1
VIDEO
Audio/Video 4-pole mini jack (M3) × 1
(see page 20)
Video: 1.0 Vp-p (75 Ω)
Audio: 0.5 Vrms
PC IN
Mini D-sub 15 Pin (Compatible with DDC2B) × 1
Y/G:
1.0 Vp-p (75 Ω) (with sync signal)
0.7 Vp-p (75 Ω) (without sync signal)
P
B/CB/B:
0.7 Vp-p (75 Ω) (without sync signal)
P
R/CR/R:
0.7 Vp-p (75 Ω) (without sync signal)
HD/VD:
1.0‒5.0Vp-p(highimpedance)
