Panasonic TK-AS41 - Attaching the Bypass Selector

12
• Keep all parts that are not used during installation, as they may be needed later if the unit is moved or the faucet
is changed.
• 沒有使用到的零件，請妥善保存，以備搬家或購買新水龍頭時之需求。
Outside-screwed faucet
• Water faucet which can attach the Alkaline Ionizer
without an accessory.
外螺紋水龍頭時
• 不需附件即可將電解水生成器連接至水龍頭上。
Aerator (not used)
• Do not use the
removed aerator.
充氣器（不使用）
• 勿使用卸下來的充氣器。
Remove the mounting nut and
adaptor.
卸下螺帽和轉接器。
1
Attach the mounting nut and
adaptor.
安上螺帽和轉接器。
2
Outside-screwed faucet
外螺紋水龍頭
Return to the original
position after removing.
卸下後，將其放回原位。
Mounting nut
螺帽
Adaptor
轉接器
Do not remove the gasket
inside the bypass selector.
不要卸下分水開關內的墊片。
Mounting nut
螺帽
Gasket
墊片
Adaptor
轉接器
Attaching the Bypass Selector/安裝分水開關
