DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
DEGAUSS COIL 18 TLK8E05140
DOOR LID 19 TKP8E1181
E P.C.B. 20 TNPH0176AH
LEFT PANEL 21 TKP8E1185
MODEL LABEL 22 TQF8E2752-1
POWER BUTTON 23 TBX8E046
RIGHT PANEL 24 TKP8E1189
SPEAKER NET 25 TKP8E1169
TOP PANEL 26 TKP8E1183
Y P.C.B. 27 TNPA1353AD
MISCELLANEOUS COMPONENTS
OUTER CARTON TPC8E4659
TOP CUSHION TPD8E633
BOTTOM CUSHION TPD8E634
I.C.s
EAROM * IC1102 X24C0504GD
COILS
COILL353 TLT150K991R
COILL373 TLT150K991R
RESISTORS
METALR419 ERG3FJ151 3W 5% 150
S.M.CARBR655 ERJ6GEYJ224 0.1W 5% 220K
S.M.CARBR680 ERJ6GEYJ303 0.1W 5% 30K
CAPACITORS
S.M. CAPC636 ECUV1H103ZFX 50V
10nF
31
