90° deflection
Audio Output : 10W+10W = 20W
Dimensions : Height : 578 mm
Width : 786 mm
Depth : 508 mm
1 Safety Precautions
3
1.1. General Guide Lines
3
1.2. Leakage Current Cold Check
3
1.3. Leakage Current Hot Check (Fig. 1)
3
1.4. X-Radiation
3
1.5. GP21 Chassis Block Diagram
4
2 Service Hints
5
2.1. Service Position for E-Board
5
2.2. Factory Mode Adjustment
5
2.3. Adjustment for White Balance
6
2.4. Adjustment for CRT CUT OFF
6
2.5. Adjustment Procedure
7
Mass : 43 kg (Net Wt.)
Specifications are subject to change without notice.
Mass and dimensions shown are approximate.
2.6. PAL Colour
8
2.7. Adjustment
8
3 Conductor Views
12
4 Schematic Diagram
13
4.1. D Board
15
4.2. A Board
20
4.3. L Board
25
4.4. G Board
29
5 Parts Locations
32
6 Replacement Parts List
33
6.1. Replacement Parts List
34
CONTENTS
Page Page
2
TX-29F350T
