Panasonic TX-29F350T - Replacement Parts List - Connectors, ICs, and Others

Ref.
No.
Part No. Part Name & Description Remarks
R373 ERJ6GEYJ821 M 820OHM,J,1/10W
R375 ERG1SJ683P M 68KOHM,J,1W
R376 ERJ6GEY0R00 M 0OHM,J,1/10W
R378 ERC12GK821 S 820OHM,J,1/2W
R380 ERJ6GEYJ392 M 3.9KOHM,J,1/10W
R381 ERJ6GEYJ162 M 1.6KOHM,J,1/10W
R451 ERJ6GEYJ223 M 22KOHM,J,1/10W
R453 ERJ6GEYJ273 M 27KOHM,J,1/10W
R454 ERJ6GEYJ183 M 18KOHM,J,1/10W
R455 ERDS2TJ223 C 22KOHM,J, 1/4W
R458 ERDS1TJ1R0 C 1OHM,J, 1/2W
R460 ERG2FJ181H M 180OHM,J,2W
R461 ERX2SJSR68H M 0.68OHM,J,2W
R465 ERJ6GEYJ681 M 680OHM,J,1/10W
R466 D0AE621JA046 C 620OHM,J, 1/4W
R467 ERJ6GEYJ472 M 4.7KOHM,J,1/10W
R4817 ERG2FJ100H M 10OHM,J, 2W
R4818 ERJ6GEYJ243 M 24KOHM,J,1/10W
R4819 ERJ6GEYJ101 M 100OHM,J,1/10W
R4820 ERJ6GEYJ243 M 24KOHM,J,1/10W
R4821 ERJ6GEYJ333 M 33KOHM,J,1/10W
R4822 ERJ6GEYJ681 M 680OHM,J,1/10W
R4823 ERJ6GEY0R00 M 0OHM,J,1/10W
R4824 ERJ6GEYJ681 M 680OHM,J,1/10W
R4826 ERJ6GEY0R00 M 0OHM,J,1/10W
R501 ERJ6GEYJ392 M 3.9KOHM,J,1/10W
R503 ERJ6GEYJ103 M 10KOHM,J,1/10W
R504 ERJ6GEYJ753 M 75KOHM,J,1/10W
R505 ERJ6GEYJ153 M 15KOHM,J,1/10W
R506 ERJ6GEYJ473 M 47KOHM,J,1/10W
R507 ERG2SJS330H M 33OHM,J, 2W
R509 ERG1SJ222E M 2.2KOHM,J,1/10W
R510 ERJ6ENF1152 M11.5KOHM, 1/10W
R512 ERJ6ENF1132 M11.3KOHM, 1/10W
R513 ERQ14AJ100E F 10OHM,J, 1/4W
R541 ERJ6GEYJ473 M 47KOHM,J,1/10W
R553 ERX1SJWR47E M 0.47OHM,J,1/10W
R556 ERJ6GEYJ124 M 120KOHM,J,1/10W
R558 ERG1DJ124P M 120KOHM,J, 1W
R559 ERJ6GEYJ561 M 560OHM,J,1/10W
R560 ERJ6GEYJ274 M 270KOHM,J,1/10W
R561 ERJ6GEYJ223 M 22KOHM,J,1/10W
R563 ERJ6GEYJ564 M 560KOHM,J,1/10W
R564 ERJ6GEYJ563 M 56KOHM,J,1/10W
R567 ERJ6GEYJ124 M 120KOHM,J,1/10W
R568 ERDS1TJ120 C 12OHM,J,1/2W
R570 ERJ6GEYJ513 M 51KOHM,J,1/10W
R571 ERJ6GEYJ103 M 10KOHM,J,1/10W
R572 ERDS1TJ104 C 100KOHM,J, 1/2W
R573 ERJ6GEYJ272 M 2.7KOHM,J,1/10W
R576 ERQ12HKR39P F 0.39OHM,J,1/2W
R581 ERQ2CJP151S F 150OHM,J, 2W
R702 ERX3FJS3R3D M 3.3OHM, J, 3W
R703 D0DK3R3J0002 W 3.3OHM, J, 10W
R704 ERJ6GEYJ203 M 20KOHM,J,1/10W
R715 ERDS2TJ182 C 1.8KOHM,J, 1/4W
R716 ERJ6GEYJ680 M 68OHM,J,1/10W
R745 ERDS2TJ123 C 12KOHM,J, 1/4W
R746 ERJ6GEYJ102 M 1KOHM,J,1/10W
R747 ERJ6GEYJ102 M 1KOHM,J,1/10W
R801 ERC12ZGK825C S 8.2MOHM,J,1/2W
R802 D0D72R7KA002 W 2.7OHM,J, 7W
R803 ERJ6GEYJ681 M 680OHM,J,1/10W
R804 ERDS1TJ682 C 6.8KOHM,J, 1/2W
R805 ERG2FJ823H M 82KOHM,J, 2W
R806 ERG2SJW104E M 100KOHM,J,1/10W
R820 ERJ6GEYJ391 M 390OHM,J,1/10W
R821 ERJ6GEYJ104 M 100KOHM,J,1/10W
R822 ERDS1TJ470 C 47OHM,J, 1/2W
R831 ERG2SJW104E M 100KOHM,J,1/10W
R832 ERG2SJW470E M 47OHM,J, 2W
R833 D0C1100JA051 M 10OHM,J, 1W
R834 ERDS2TJ102 C 1KOHM,J, 1/4W
Ref.
No.
Part No. Part Name & Description Remarks
R840 RCR100TAJ825 C 8.2MOHM,J, 1W
R841 ERDS2TJ393 C 39KOHM,J, 1/4W
R842 ERDS2TJ221 C 220OHM,J, 1/4W
R843 ERX2FZJR12H M 0.12OHM,J, 2W
R844 ERX2FZJR15H M 0.15OHM,J, 2W
R845 ERDS2TJ473 C 47KOHM,J, 1/4W
R846 ERDS2TJ182 C 1.8KOHM,J, 1/4W
R850 ERJ6GEYJ433 M 43KOHM,J,1/10W
R851 ERJ6GEYJ103 M 10KOHM,J,1/10W
R852 ERJ6GEYJ752 M 7.5KOHM,J,1/10W
R853 ERJ6GEYJ752 M 7.5KOHM,J,1/10W
R854 ERJ6GEYJ752 M 7.5KOHM,J,1/10W
R855 ERJ6GEYJ752 M 7.5KOHM,J,1/10W
R860 ERG3FJ470H M 47OHM,J, 3W
R862 ERDS2TJ104 C 100KOHM,J, 1/4W
R863 ERDS2TJ152 C 1.5KOHM,J, 1/4W
R865 ERDS1TJ100 C 10OHM,J, 1/2W
R867 ERDS1TJ751 C 750OHM,J, 1/2W
R868 ERDS1TJ122 C 1.2KOHM,J, 1/2W
R869 ERJ6GEYJ153 M 15KOHM,J,1/10W
R870 ERJ6GEYJ103 M 10KOHM,J,1/10W
R871 ERJ6GEYJ272 M 2.7KOHM,J,1/10W
R872 ERJ6GEYJ103 M 10KOHM,J,1/10W
R873 ERJ6GEYJ472 M 4.7KOHM,J,1/10W
R874 ERJ6ENF1873 F 187KOHM,J,1/10W
R875 ERJ6ENF3012 F 30.1KOHM,J,1/10W
R876 ERJ6ENF5761 M5.76KOHM, 1/10W
R877 ERJ6ENF2401 M 2.4KOHM, 1/10W
R879 ERJ6ENF4301 M 4.3KOHM, 1/10W
R880 ERJ6GEYJ473 M 47KOHM,J,1/10W
R886 ERG2SJW273E M 27KOHM,J, 2W
R887 ERJ6ENF5362 M53.6KOHM, 1/10W
R888 ERJ6ENF2401 M 2.4KOHM, 1/10W
R889 ERJ6ENF3092 F 30.9KOHM,J,1/10W
R891 ERJ6GEYJ473 M 47KOHM,J,1/10W
R895 ERJ6GEYJ103 M 10KOHM,J,1/10W
R896 ERDS2TJ472 C 4.7KOHM,J, 1/4W
R897 ERJ6ENF1203 F 120KOHM,J,1/10W
R898 ERJ6ENF3902 M 39KOHM, 1/10W
R901 ERJ6GEYJ471 M 470OHM,J,1/10W
R902 ERDS2TJ122 C 1.2KOHM,J, 1/4W
R903 D0AE100JA046 C 10OHM,J, 1/4W
R904 ERG3FJ331H M 330OHM,J, 3W
R905 ERJ6GEYJ471 M 470OHM,J,1/10W
R906 ERDS2TJ122 C 1.2KOHM,J, 1/4W
R907 ERDS2TJ124 C 120KOHM,J, 1/4W
R908 ERDS2TJ124 C 120KOHM,J, 1/4W
R909 D0AE100JA046 C 10OHM,J, 1/4W
R910 ERG2SJ181E M 180OHM,J, 2W
R914 ERJ6GEYJ331 M 330OHM,J,1/10W
R915 ERC14GK220 S 22OHM,J,1/10W
R916 ERJ6GEY0R00 M 0OHM,J,1/10W
R917 ERJ6GEYJ471 M 470OHM,J,1/10W
R918 ERJ6GEYJ471 M 470OHM,J,1/10W
R919 ERJ6GEYJ471 M 470OHM,J,1/10W
TRANSFORMERS
T501 ETH19Y212BZ H DRIVE TRANS
T551 ZTFP14508A FLYBACK TRANS
T801 ETS42AE3M6AD SWITCHING TRANS
OTHERS
A1 K1KA64BA0149 CONNECTOR
A2 K1KA08BA0055 CONNECTOR
CF806A D4DDE9R00002 POSISTOR
D1 K1KB64AA0096 CONNECTOR
D3 K1KA07AA0190 CONNECTOR
D15 K1KA04AA0093 CONNECTOR
D16 K1KA05AA0190 CONNECTOR
D17 K1KA03AA0190 CONNECTOR
D26 K1KA09AA0190 CONNECTOR
D27 K1KA09AA0190 CONNECTOR
F801 K5D502BLA016 FUSE
FL1134 ELKE103FA NOISE FILTER
FL1180 ELKE103FA NOISE FILTER
41
TX-29F350T
